• Model NO.：DH-PS-1T
• OEM：Yes
• Transport Package：Standard Exporting Wooden Package
• Trademark：DahoMeter
• Origin：Dongguan, China
• Production Capacity：300 Sets,Month

Basic Info.

Model NO. DH-PS-1T OEM Yes Transport Package Standard Exporting Wooden Package Trademark DahoMeter Origin Dongguan, China Production Capacity 300 Sets/Month

Product Description

DH-PS-1T Pneumatic Press Plastic Rubber Slicer Instrument



Introduction

 The pneumatic slicer is mainly used for rubber cutting standard test pieces, and it is necessary to match the standard knife die.and connect the gas source above 4KG.

Specification

 1. Load: 1000KG. 2. Platen diameter: Ф120 mm. 3. Base plate: 230X250mm. 4. Effective height: 100mm. 5. Machine size: 280X330X430mm. 6. Machine weight: about 20 kg.
 Operation
 1. Place the machine on a flat surface, adjust the four feet to make it stable.and put the cutting glue.
 2. Open the ventilation source, adjust the rear oil-water separator valve switch, adjust the barometer to at least 4KG.
3. Put the PU glue, put the film on the glue, then put the knife mold, then hold the red button switch at the same time with both hands (for safety, both hands must be pressed at the same time), press the plate down on the knife mold, stay for a few seconds, so that the rubber is fully cut off, and at the same time let go, take out the test piece.
 4. When you are finished, please turn off the air supply.



Shipping And Handling



Items will be shipped out within 3 to 5 working days upon verification payment.

Items will be shipped out via Fedex,DHL or UPS.it will take around 5 to 7 days to get your door given considering everything goes well.





About  Company


We, Dongguan Hongtuo Instrument Co., Ltd, a China based company, are pleased to introduce ourselves as a notable testing equipments and machines manufacturer.Our company was established in the year 2000 with two primarily motto, which includes complete client satisfaction and to reach top-most position in the international market. The exceptional quality of our products like Gold Tester,Gold Testing Machine,Density Meter,Universal Tensile Testing Machine,Climatic Chamber,Melt Flow Index Tester,Charpy Impact Testing Machine,Tap Density Tester,Abrasion Tester,Ultrasonic Flaw Detector,Surface Roughness Tester and other Laboratory Testing Equipment, etc. is our company's USP.
