• Model NO.：CPJ-3015
• Testing Before Delivery：Yes
• After-sale Customer Service：Yes
• Transport Package：Standard Exporting Wooden Package
• Trademark：DahoMeter
• Origin：Dongguan, China
• HS Code：9027809900
• Production Capacity：300 Sets,Month

ModelCPJ-3015TableThe metal table's size(mm)340X152The glass table's size(mm)196X96X-axis travel(mm)150Y-axis travel(mm)50Z-axis travel(mm)90 for focusMeasuring accuracy(3+L/50)µmResolution(X-axis, Y-axis)0.0005 mmScreen size (mm):Ø 312 Used range>Ø 300(with the meter line)Screen rotary range:0°~360°Rotary angle Resolution1´ or 0.01°LensMagnification10X option20X option50X option100X optionObject viewØ30Ø15Ø6Ø3Working distance77.7mm44.3mm38.425.3Max. work-piece height80mm80mm80mm80mmData processing systemDC-3000 multi-function data processing system ,appearing in English, can be used to gather the data and measure the point ,line, circle, angle and distanceColdBy three fansIlluminationThe illumination of transmission and reflection: 24V/150W-halogen lamp.Power110V/220V(AC), 50/60HZ, Total power=400WDimensions780*780*1100mmWeight180kg



Packaging & Shipping:

Company Information

We, Dongguan Hongtuo Instrument Co., Ltd, a China based company, are pleased to introduce ourselves as a notable testing equipments and machines manufacturer.Our company was established in the year 2000 with two primarily motto, which includes complete client satisfaction and to reach top-most position in the international market. The exceptional quality of our products like Gold Tester,Gold Testing Machine,Density Meter,Universal Tensile Testing Machine,Climatic Chamber,Melt Flow Index Tester,Charpy Impact Testing Machine,Tap Density Tester,Abrasion Tester,Ultrasonic Flaw Detector,Surface Roughness Tester and other Laboratory Testing Equipment, etc. is our company's USP.


Certification
