• Model NO.：TQD-03
• Power Source：AC220V
• Transport Package：Wooden Case
• Specification：700*680*800mm
• Trademark：SUZHOU QIANTONG
• Origin：Jiangsu, China
• HS Code：9031809090
• Production Capacity：114 Set,Year

Basic Info.

Model NO. TQD-03 Power Source AC220V Transport Package Wooden Case Specification 700*680*800mm Trademark SUZHOU QIANTONG Origin Jiangsu, China HS Code 9031809090 Production Capacity 114 Set/Year

Product Description

1. Qiantong main scope of testing machineElectronic universal material testing machine, Horizontal tension testing machine, Hydraulic universal testing machine, MFI, Charpy Impact, Izod Impact, HDT-Vicat tester, Hardness tester, Torsion tester, Metallographic series, Oven and so on. (We accept customization.) Product features
Tqd-03 air resistance and respiratory resistance tester is used to measure the inspiratory and expiratory resistance of masks under specified conditions, and also can be used to measure the air penetration resistance of textiles, cotton floc, space cotton, masks, etc. It is applicable to the inspection and testing of mask products by mask manufacturers and national labor protection equipment inspection institutions

The product feature

· 7-inch color touch screen, easy to operate
· the instrument consists of an air source that can adjust the flow rate, a human head mold specified in the standard, an inhaling and exhaling double casing system, and an airflow resistance measurement system.
· high sensitivity of flow sensor, with minimal initial flow
· the flow sensor chip adopts thermal mass flowmeter, without temperature and pressure compensation, ensuring the high precision measurement of the sensor. The accuracy is ±2%.
· multiple sensors are assembled on a single flow sensor chip, which greatly improves the range ratio of the sensor
· the flow sensor has high zero stability, high accuracy in full range, excellent repeatability, low power consumption, low voltage loss and fast response speed.
· the micro-manometer sensor adopts two-wire system with high precision and good stability; The use of explosion-proof design is safe and reliable.
 4. Technical parameters

Name	standard
Flowmeter range	0 L/min~100L/min
Flow resolution	±2%
pressure difference	-1500Pa~1500Pa
Pressure resolution	0.1Pa
Precision	0-99h optional
diameter	220VAC 50Hz
power	30 kg

5. Test application

base	mask	It is suitable for testing the airflow resistance and respiratory resistance of daily protective masks, medical masks and surgical masks
extend	textile	Applicable to the determination of air penetration of textiles

FAQ
Q:Are you a trade company or factory?
A:Our company is a factory and directly sales.
Q:Can your company accept customization?
A: Yes. Our machines can be customized by client.
Q:How to guarantee your after-sales service?
A:Our philosophy is one year warranty and lifetime service. After the warranty period is exceeded, if there is any problem, we will provide support for you in time. (only charge travel expense and parts cost at most.)
Q:What is the language about software?
A:It can switch between Chinese and English.
Q:May the customer not use your company's computer?
A:Sure. But please tell us what type your computer is. We need to confirm your computer can install the software. And we can subtract the price of computer from offer.
