• Model NO.：CPJ-3015CZ
• After-sale Customer Service：Yes
• Transport Package：Standard Exporting Wooden Package
• Trademark：DahoMeter
• Origin：Dongguan, China
• HS Code：9027809900
• Production Capacity：300 Sets,Month

ModelCPJ-3015CZCPJ-3020CZCPJ-3025CZX-axis Travel (mm)150200250Y-axis Travel (mm)100100150Metal table size (mm)354×228404×228450×280Glass table size (mm)210×160260×160306×196Resolution (μm)0.5Indication error (mm)E1XY=(2.5+L/100)Z-axis Travel (mm)100Weight (kg)170175180Dimension (mm)780×810×1120780×810×1120780×810×1120Projection screenSize (mm)Ф 312Rotary range0~360°Resolution1' or 0.01°LensMagnification10× (Optional)20× (Optional)50× (Optional)100× (Optional)Field of view (mm)Ф30Ф15Ф6Ф3Working distance (mm)77.744.338.425.3Max. measuring Height (mm)90909090

Power supply: AC 100-240V 50/60Hz. Total power: 400W

Packaging & Shipping

Company Information

We, Dongguan Hongtuo Instrument Co., Ltd, a China based company, are pleased to introduce ourselves as a notable testing equipments and machines manufacturer.Our company was established in the year 2000 with two primarily motto, which includes complete client satisfaction and to reach top-most position in the international market. The exceptional quality of our products like Gold Tester,Gold Testing Machine,Density Meter,Universal Tensile Testing Machine,Climatic Chamber,Melt Flow Index Tester,Charpy Impact Testing Machine,Tap Density Tester,Abrasion Tester,Ultrasonic Flaw Detector,Surface Roughness Tester and other Laboratory Testing Equipment, etc. is our company's USP.




Certification
