Product Description

Laboratory Automatic 20L Asphalt Mixture Mixer For Bitumen and Bituminous Mixtures



Introduction:

The Automatic 20L Asphalt Mixture Mixer is designed and made as per industrial standard T 0702-2011 Production Method for Test Specimen of Bituminous Mixture(Compaction method) in JTG E20-2011 Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering. It is used to blend the test specimen of bituminous mixtures before production.

The size of Automatic 20L Asphalt Mixture Mixer is small, space saving and easy to operate. It is a preferred instrument for blending the bituminous mixture for bitumen production companies, road and bridge building units, colleges and scientific research institutes.



Features:

1. The Automatic 20L Asphalt Mixture Mixer adopts advanced microcomputer control technology. Temperature can be set from ambient to 200ºC at will and automatically adjusted by PID. The blending time can be controlled automatically. It achieves the automation for operation.
2. The Automatic 20L Asphalt Mixture Mixer has protecting function for phase sequence which can prevent the machine from damage because of phase sequence fault.
3. Floor type structure. Reasonable design and easy to use.


Specifications:

1. Blending amount:   20L
2. Temperature control range:   Room temperature~200ºC
3. Temperature control accuracy:  ±5ºC
4. Timing range:    (0~999)s
5. Timing accuracy:    ±0.1s
6. Rotation rate of paddle:  Complete revolution 47R/min, Autorotation 76R/min
7. Blending motor:  Alternating current 380V, 550W;1400R/min;50Hz
8. Lifting motor:  Alternating current 380V,250W;1400R/min;50Hz
9. Overall dimension:  600mm*400mm*1300mm
10. Net weight:  215Kg
11. Power supply:  AC(380±10%)V, 16A; 50Hz(three-phase four-wire with null line
12. Ambient temperature:   (-5~+50)ºC
13. Relative humidity:    ≤80%
