• Model NO.：HJ-65
• Power Source：AC220V
• Zigzag Load：0~1000g
• Test Speed：10~200 Times,Min
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-65 Power Source AC220V Zigzag Load 0~1000g Test Speed 10~200 Times/Min Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Product Description:
This machine is mainly used for flexural testing of flexible circuit boards (commonly known as software circuit boards); such as mobile phones, PDAs, electronic dictionaries, laptops and other electronic products FPC flexible boards, flexural resistance, flexural life testing test.
Features:
a. Driven by Taiwan stepping motor, high-precision positioning, low noise, long-term use;
b. Using a special power rectifier circuit to improve the long-term use ability and anti-interference of the motor and actuator;
c. Program-controlled origin reset, no need to place the fixture in place by hand;
d. LCDPLC, stepper motor drive!
e. Parameter settings include: bending angle, speed, number of tests, and the motor returning to the origin, etc.; automatic counting, the sample is bent until it breaks
      When the line cannot be powered on, it can automatically stop the operation


model	HJ series
zigzag load	0~1000g
Test speed	10~200 times/min
test trip	45~100mm
FPC maximum width	5~100mm(max)
Zigzag R angle	0.38, 0.8, 1.2, 2 can be replaced
angle	0~1800 (can be set arbitrarily)
count setting	0~999999 times
volume	W450mm × D380mm × H700mm
weight	45kg
power supply	1∮ AC 220V 3.5A (according to country or designation)

FAQ
Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.

3.  What about the services and product' quality?
Service: ,Design service,Buyer lable service.
Quality: Each instruments must be carried out 100% quality examination and test, the finished products must through a third party
calibration institutions before shipping and delivery goods.
