Automatic Electronic Torsion Testing Machine Metal Material Torsional Fatigue Detector

Dongguan Hongjin Test Instrument Co., Ltd.
  • After-sales Service:Lifetime Maintenance
  • Warranty:1 Year
  • Type:Torque Testing Machine
  • Accuracy Grade:0.5
  • Load Way:Electronic Load
  • Loading Method:Static Load

Base Info

  • Model NO.:HJ-69
  • Display:Digital
  • Weight:0-100Kg
  • Power Source:AC220V
  • Maximum Torque:5nm, 10nm, 20nm, 50nm, 100nm (Customizable)
  • Testing Machine Level:Level 0.5,Level 1
  • Torque Resolution:0.001~0.01 N M
  • Equipment Weight:About 200kg
  • Transport Package:Fumigation-Free Standard Export Wooden Box
  • Trademark:Hongjin
  • Origin:China
  • Production Capacity:1000 Sets, Month

Description

Basic Info.

Model NO. HJ-69 Display Digital Weight 0-100Kg Power Source AC220V Maximum Torque 5nm, 10nm, 20nm, 50nm, 100nm (Customizable) Testing Machine Level Level 0.5/Level 1 Torque Resolution 0.001~0.01 N M Equipment Weight About 200kg Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Introduce
The automatic torsion testing machine is mainly used for torque testing of various metal materials, non-metals, parts, finished products, semi-finished products, etc. It can issue detailed A4 paper test curves, and test reports can be stored, copied, and edited. Ideal testing equipment.


Parameter
Maximum torque5Nm, 10Nm, 20Nm, 50Nm, 100Nm (customizable)
Testing machine levelLevel 0.5/Level 1
Torque Resolution0.001~0.01 N m
Torsion speed control range0.1°-720°/min can be customized
Corner measurement range0°±99999.99°
Indication repeatability relative error<0.5%
Power supply220V, 50Hz
Loading methodFully automatic
Equipment weightAbout 200KG
Torque measurement range1%FS-100%FS
Test plus torque directionBoth directions
Torque Resolution1/±300000
Test stroke300mm (can be customized)
Relative error of torque indication<±0.5%/<±1%
Relative error of torsion angle indication<±0.5%
Torsion attachmentThree-jaw chuck can be customized
ExteriorShould meet the requirements of GB/T2611

Features
It is mainly used to test the torsional stiffness performance, torsional strength test, torsional strength test of various auto parts, mechanical parts, various tools, torsion springs, fasteners, bolts, welding parts, connectors, components, torsion bars and other products of various specifications. Fatigue test performance, etc. The tested sample is installed between the clamps with adjustable space, which can adapt to the test of torsional mechanical properties of different products. The automatic static torsion testing machine adopts computer control operation, which can collect data such as torque, peak value, angle, curve, etc.; the display shows the torque-time, torsion angle-time, torque-torsion angle test curve of the tested sample; it can realize the test It is the first choice for customers with functions such as data storage, examination and acquisition, and printing of test reports.

Automatic Electronic Torsion Testing Machine Metal Material Torsional Fatigue Detector
The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.


Automatic Electronic Torsion Testing Machine Metal Material Torsional Fatigue DetectorAutomatic Electronic Torsion Testing Machine Metal Material Torsional Fatigue DetectorAutomatic Electronic Torsion Testing Machine Metal Material Torsional Fatigue Detector
Automatic Electronic Torsion Testing Machine Metal Material Torsional Fatigue Detector
Hongjin's services:
If you encounter any problems during future testing, we promise we will reply you within 48 hours and provide a solution within 3 working days. We can provide operation video and English operation manual. We can provide video conferencing.
1. Pre-sales service
    --24-hour online service for your consultation.
    -- Help with choosing the right model, and a range of services, people, advice.
   --Provide laboratory planning and pre-sales technical guidance.
2. Intermediate service
    -- give you the best offer
    --Provide discounts on multiple sets of orders
    -- Do the customer's request:
    --Choose a payment term that is convenient for you.
    --Prompt production and delivery, keep you informed.
    -- Invoice value can be provided according to your needs to reduce tax.
3. After-sale service
   --1 year warranty service and lifetime maintenance.
   --Technical engineers can provide 24-hour after-sales guidance.
   --Replacement of some parts
   --Remote control technical consultation
   --Machine lifetime maintenance service
4. Commitment:
We will sign a letter of commitment at the same time as signing the contract, which will increase your confidence in us.
5. Good packaging:
Simulation animation customers cover with bubble film before putting them into wooden boxes, which not only has good shock absorption, impact resistance, heat sealing, but also has the advantages of non-toxic, odorless, moisture-proof and corrosion-proof, and good transparency.
