• Model NO.：HME-702
• Mass Scope of Workpiece：<900kg
• Load Way：Electronic Load
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：0-100kg
• Power Source：AC220V
• Type：Electric Power Tester
• Maxcapacity：Electric Power Tester
• Accuracy Grade：0.1%
• Oil Cylinder Position：No
• AC Output Accuracy：0.2%
• PC Connection：485
• Transport Package：Standard Export Wooden Package
• Specification：400× 300× 180mm
• Trademark：Relaytestar
• Origin：Hubei China
• HS Code：9030390000
• Production Capacity：100px,Week

Product Description

Universal Multi Application Protection Relay Tester
HMESetting Range

6-Phase AC(L-N)

6x0…40A

3-Phase AC(L-N)

3x0…80A

1-Phase AC(LL-LN)

1x0…240A

DC(L-N)

6x0…±20 A

Power

6-Phase AC(L-N)

6x300VA At 40A

3-Phase AC(L-N)

3x450VA At 80A

1-Phase AC(LL-LN)

1x1000VA At 240A

DC(L-N)

6x120VA At 20A

Accuracy

AC: ±1mA(≤0.2A), ≤0.1% (0.2~40A)

DC: ±5mA(0.2~0.5A), ≤0.2% (0.5~20A)

Resolution

1mA

Setting Range

6-Phase AC(L-N)

6x0…150V

3-Phase AC(L-N)

3x0…300V

DC(L-N)

6x0…±175V

Power

6-Phase AC(L-N)

6x80VA At 150V

3-Phase AC(L-N)

3x100VA At 300V

DC(L-N)

6x80VA At 175V

Accuracy

AC: ±2mV(0.2~2V), ≤0.1% (2~150V)

DC: ±10mV (0.5~5V), ≤0.2% (5~175V)

Resolution

1mV

Auxiliary DCFrequency

Range: 0~1200Hz

Accuracy:<1mhz(0~65hz);<10mhz(65~450hz);<20mhz(450~1200hz)<>

Resolution: 0.001Hz

Phase

Range: -360° ~+360°

Accuracy: 0.1°

Resolution: 0.01°

Harmonic

Superposition Order: 2~24 Times

Distortion: ≤0.5%
