Factory Direct AC Series Resonant Test Equipment for Transformer
Sansion Power Electric Co., Ltd.- Max Diameter of Workpiece：900mm
- Mass Scope of Workpiece：<900kg
- Type：Strength Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Electronic Load
Base Info
- Model NO.：SXBP
- Loading Method：Static Load
- Display：LCD
- Control：Auto
- Power Source：AC 110V,220V at Customized
- Oil Cylinder Position：Under
- AC Withstand Test for：Electric Equipments of Substation at 10kv~500kv or
- Output Frequency：20-300Hz
- Power Supply：220V or 380V
- Frequency Adjustment：Fineness 0.1Hz, Instability 0.05%
- Quality Factor：Max.30-90
- Transport Package：Plywood Case
- Specification：ISO9001 SGS
- Trademark：Sansion
- Origin：Wuhan, China
- HS Code：9030339000
- Production Capacity：100 Units
Description
Model
Test Object
Main Configurations:
AC power source
Exciting Transformer
Reactor
Capacitive Voltage Divider:
SXBP-27/54/108-108
Test Frequency: 20~300Hz
31500kVA/35KV Power Transformer
10KW 1 unit
10KW 1 unit
27KV/1A
4 Units
Frequency: 20-300Hz
120KV
35KV circuit breaker, busbar, insulator
10KV(300mm2) cable 2000m
35KV(300mm2) cable 500m
SXBP-54/108/216-216
Test Frequency: 20~300Hz
110KV Circuit breaker and busbar
15KW 1 unit
15KW 1 unit
54KV/1A
4 Units
Frequency: 20-300Hz
110KV GIS ≤ 10 intervals
35KV (300mm2) cable 1500m
10KV (300mm2) cable 3000m
110KV Full Insulated Transformer
SXBP-65/130/260-520
Test Frequency: 20~300Hz
110KV Circuit Breaker and busbar
30KW 1 Unit
30KW 1 Unit
65KV/2A 4 Units
Frequency: 20-300Hz
300KV
110KV GIS ≤ 10 intervals
110KV (300mm2) cable 800m
35KV (300mm2) cable 3000m
10KV(300mm2) cable 200m
110KV Full Insulated Transformer
SXBP-45/90/135/180/270-270
Test Frequency: 20~300Hz
110KV Insulator, switchgear, GIS and etc.
20KW 1 unit
20KW 1 unit
45KV/1A Six Units
Frequency: 20-300Hz
200KV
50MW/110KV Full Insulated Transformer
110KV (300mm2) cable 200m
35KV Power Transformer, switchgear, CT/PT, cable, and etc.
20MW hydrogenerator
10KV power transformer, switchgear, CT/PT, cables and etc.
SXBP18/36/54
Test Frequency: 20~300Hz
10KV (300mm2) cable 2000m
5KW 1 Unit
5KW 1 unit
27KV/1A 2 units or
18KV/1A 3 units
Frequency: 20-300Hz
60KV
35KV (300mm2) cable 500m
10KV power transformer, switchgear, CT/PT and etc.
√ Model SXBP-27/54/108-108, SXBP is the model of series, 27/54/108 is: voltage of one reactor (KV)/voltage of two reactors in series connection/voltage of four reactors in series connection. 108 is the total capacity (KVA).
√ The test object is the common configuration for reference only. For details, please contact with us. If the capacity of your equipment is small and voltage is too low, can add more reactors to increase the capacity, and add more divider to increase the test voltage.
Please contact with us for further information, our technically expereinced expertise team will select correctly designed test set for you.
Warranty: One year quality guarantee after shipment.
