ASTM F2029 Gradient Aluminum Foil Plastic Films Heat Seal Strength Test Machine Manufacturer

Pubtester Instruments Co., Ltd.
  • Sealing Temperature:Room Temperature ~ 300 °c
  • Sealing Pressure:50~ 700 Kpa
  • Temperature Accuracy:± 0.2 Degree
  • Dwell Time:0.1 ~ 999.9s
  • Temperature Uniformity:± 1 Degree
  • Sealing Area:330 mm X 10 mm

Base Info

  • Model NO.:HSR-05
  • Transport Package:Veneer Case
  • Trademark:Pubtester
  • Origin:Jinan, Shandong
  • Production Capacity:10 Sets,Quarter


ApplicationsSealing SurfacesVarious types of sealing surfaces can be customized upon user's requirements.Jelly CupsJelly cups can be sealed with special testing accessories.Soft Plastic PipesSoft plastic tubes can be sealed from one end and become packaging containers
Technical Specifications
Sealing TemperatureRoom temperature ~ 300 °C
Sealing Pressure0.1MPa ~ 0.7 MPa
Dwell Time0.1~ 999.9s
Temperature Accuracy±0.2 °C
Temperature Uniformity± 1 °C
Temperature Gradient≤20°C
Heating ModeDouble Heating Surfaces (Independent Control)
Sealing Area40 mm × 10 mm x 5 groups (Customization)
Power SupplyAC 220V 50Hz / AC 120V 60HZ
Gas Supply Pressure0.1MPa~0.7MPa (Not in Supply Scope)
Port SizeΦ8 mm PU Tubing
Instrument Dimension400 mm (L) × 320 mm (W) × 500 mm (H)
Net weight70kg

ASTM F2029, QB/T 2358, YBB 00122003

Standard Configuration:Instrument, Pedal Switch, Micro-printer

Optional Configuration:Communication cable

Note: 1. The gas supply port of the instrument is Φ8 mm PU Tubing;
            2. Customers will need to prepare for gas supply.

ASTM F2029 Gradient Aluminum Foil Plastic Films Heat Seal Strength Test Machine Manufacturer
ASTM F2029 Gradient Aluminum Foil Plastic Films Heat Seal Strength Test Machine Manufacturer


Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.

Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.

How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.

Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.

How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.

How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
