• Model NO.：HTHY XY150
• Oil Cylinder Position：Under
• Transport Package：Standard Export Wooden Box
• Trademark：tianpeng
• Origin：China
• HS Code：90248000
• Production Capacity：1000PCS,Year

Basic Info.

Model NO. HTHY XY150 Oil Cylinder Position Under Transport Package Standard Export Wooden Box Trademark tianpeng Origin China HS Code 90248000 Production Capacity 1000PCS/Year

Product Description

Touch-screen gyratory compactor

The Gyratory Compactor is built to SH RP specifications.It produces asphalt specimens that best predict long-term pavement performance. Automatically measuring the specimen height during consolidation, produces a densification graph that the designer can use to produce the best possible paving mixture.

Weight: 370 kg
Mould weight: 7.4 kg
Overall height: 190 cm
Motor nominal speed: 1800 cycle/min
Gyration rate: 30±0.5 cycles/min0-300 mm
displacement range:Gyratory compaction<0.02°
accuracy:Gyratory compaction angle
Number of gyratory: adjustable up to 999
Number of compaction: from 1 to 5
Pressure accuracy: <±60 Kpafrom 100 to 1000 Kpa
Vertical load: continuously adjustableModel: HTHY XY150
