ASTM D3420 Composite Films Sheet Plastic Film Pendulum Impact Resistance Testing Machine China Price
Pubtester Instruments Co., Ltd.- Impact Energy：1 J, 2 J, 3 J (Standard), 5j (Optional)
- Resolution：0.001 J
- Impact Head Size：Dia: 25.4 mm, 19 mm, 12.7 mm
- Specimen Clamp Diameter：Dia;89 mm, 60 mm
- Specimen Size：100 mm X 100 mm or & Dia 100 mm
- Transport Package：Veneer Case
Base Info
- Model NO.：FPP-01
- Trademark：Pubtester
- Origin：Jinan, Shandong
- Production Capacity：10 Sets,Quarter
Description
Basic ApplicationFilm plastic films, sheets, composite films and aluminized films Paper/
Paper board paper and paper board, e.g. aluminized paper for cigarette packages and Tetra Pak materials
Technical Specifications
Standards
ASTM D3420, GB/T 8809, NF T54-116
Configuration
Standard configuration:Instrument, Pendulums of 1J, 2J and 3J, Standard Impact Heads of Φ25.4mm and Φ19mm, Standard Clamp Plates of Φ89mm and Φ60mm, O-ring, Micro-printer
Optional configuration:Pendulum of 5J, Customized Impact Head, O-ring, Professional software, Communication cable
Note:
1. The gas supply port of the instrument is Φ6 mm PU Tubing;
2. Customers will need to prepare for gas supply.
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
Paper board
Technical Specifications
| Specifications | FPP-01 |
| Impact Energy | 1 J, 2 J, 3 J (Standard), 5J (optional) |
| Resolution | 0.001 J |
| Impact Head Size | Ф25.4 mm, Ф19 mm, Ф12.7 mm (Customization) |
| Specimen Clamp Diameter | Ф89 mm, Ф60 mm |
| Specimen Size | 100 mm x 100 mm or Ф100 mm |
| Gas Supply Pressure | 0.6MPa (Prepared by user) |
| Port Size | Φ6 mm PU Tubing |
| Power Supply | AC 220V 50Hz/120V 60Hz |
| Instrument Dimension | 600mm(L)×390mm(W)×600mm(H) |
| Net Weight | 64kg |
Standards
ASTM D3420, GB/T 8809, NF T54-116
Configuration
Standard configuration:Instrument, Pendulums of 1J, 2J and 3J, Standard Impact Heads of Φ25.4mm and Φ19mm, Standard Clamp Plates of Φ89mm and Φ60mm, O-ring, Micro-printer
Optional configuration:Pendulum of 5J, Customized Impact Head, O-ring, Professional software, Communication cable
Note:
1. The gas supply port of the instrument is Φ6 mm PU Tubing;
2. Customers will need to prepare for gas supply.
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
