Best Selling Low Price High Voltage Circuit Breaker Operating Mechanism Tester

Sansion Power Electric Co., Ltd.
  • Display：LCD
  • Control：Computer Control
  • Weight：10kg
  • Power Source：AC 110V,220V at Customized
  • Time Test：6 Channels (12 Channels for Option)
  • Data Storage：100 Groups

Base Info

  • Model NO.：SXGK
  • Test Range：0.1ms~999.99ms
  • Transport Package：Plywood Case
  • Specification：ISO9001 SGS
  • Trademark：Sansion
  • Origin：Wuhan, China
  • HS Code：9030820000
  • Production Capacity：100 Units

Description

Velocity test:Open(Close)velocityPointed periods of time(travel period or angle period)average speedOpen(Close)max.velocity.Range:1mm Sensor:0.01~25.00m/s0.1mm sensor: 0.001~2.50m/s0.5°angle sensor: 1cycle/ 0.5°Accuracy:1mm Sensor  ±(1% reading+1digit)0.1mm sensor ±(2% reading +1digit)0.5°angle sensor ±(1% reading+1digit)Travel test:Active contactor travelContactor travel (open distance)Overshoot travel or bounce travel (amplitude)Sensor:50mm,Resolution:0.1mmSensor:300mm(option),Resolution:1mm360line sensor:360,resolution:0.5 ,accuracy: ±1%Screen:320×240LCDData Storage:100 groupsPrinter:Build-in thermal printerAC source:AC 220V ± 10%;50Hz ± 2%DC source:Output voltage:30~245V continuous adjustment,output current:≤ 15A(short time)Control unit oversize:380×280×140mmWorking Conditions:Temperature:-10ºC~+50ºC  RH:≤90% Warranty: One year quality guarantee after shipment.

Please kindly contact with us for further information.
