Hot Cold Climate Humidity Test Chamber for Test Camera Telescope Reliability Testing
Guangdong Komeg Industrial Co., Ltd.- After-sales Service:24 Hours on Line Services
- Warranty:1 Year
- Type:Material Testing Machine
- Control:Computer Control
- Weight:100-500Kg
- Power Source:AC380V
Base Info
- Model NO.:KMH-225
- Temp. Range:-40oc~+150oc or -104of~+302of
- Humidity Range:20-98%R.H.
- Temp. Constancy:+,-0.5oc
- Humidity Constancy:+,-2.5%R.H.
- Humidity Uniformity:+,-3.0%R.H.
- Heat up Time:-40 Oc~+100 Oc Within 45mins
- Pull Down Time:+20 Oc~-40 Oc Within 60mins
- Inner Size:W600*H600*D460mm
- Transport Package:Strong Plywood Case, Meet International Standards
- Specification:Standard and Customized
- Trademark:KOMEG
- Origin:Dongguan, China
- HS Code:90321000
- Production Capacity:1000 Sets Per Yesr
Description
Environmental Temperature and Humidity Testing ChamberSecifications ( at +20°C room temp. Or+25°C water temp with empty load) Model KMH-L series 150L 225L 408L 800L 1000L Interior sizel W(mm) 600 700 700 1000 1000 H(mm) 600 700 750 1000 1000 D(mm) 460 480 800 800 1000 Exterior size W(mm) 880 980 980 1280 1280 H(mm) 1730 1890 1940 2160 2160 D(mm) 1400 1460 1740 1750 1950 Weight(KG) 250 300 420 530 600 Temp. range -40 °C ~ +150°C Humidity Range 20 ~ 98&R.H. Temp. constancy ±0.5ºC Humidity constancy ±2.5%R.H Humidity uniformity ±3.0 % R.H ±5.0 % R.H Heat up time -40°C ~+100°C , within 45 min Pull down time +20°C ~ -40°C , within 60 min Equipment Power 7.5 7.5 8.5 14.5 14.5 Ambient Temp. 5ºC ~+35ºC Standard accessories Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m Safety device (standard) No fuse breaker, over pressure over heat and over current protection for compressor,
Over temp. protect, over load protect of blower, dry heat protection Control System Balanced Temperature & Humidity Control System Refrigeration system Air Cooled ( Water Cooled Type is option ) Hermetic compressor,Single stage refrigeration system, CFC-Free refrigerant(HFC-507/HFC-23) Controller Panel:7-inch LCD Touch panel, Chinese or English display selectable Operation model :Program or fix point running Memory capacity :120programs,1200steps, All repeat 999 cycles, part repeat 99 cycles Interior material Stainless Steel Plate ( SUS 304 ) Exterior material Baked Painting Steel Or Stainless steel(SUS304) Insulation material Rigid polyurethane Foam and Glass Fiber Wool System Balanced & Humidity Control System Wiring method AC 380±10 % 50Hz ,3 phase 4 wires +Ground Wires Note:
1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
In addition to Warm cold climate test chamber, we also produce:
Programmable Temperature Humidity Tester; Temperature Humidity Testing Machine; Enviromental Testing Machine; High Low Temperature Tester; Temperature Humidity Test Chamber; Temperature Humidity Chamber; Environmental Test Chamber; Temperature Humidity Testing Equipment; Climatic Test Chamber; Climatic Control Chamber; Is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity endurance, suitable for quality control of the industries of electron, electrical equipment, vehicle, metal, foodstuffs, chemistry, building materials, luggage, adhesion tape, printing, packaging, etc.
