• Model NO.：SXGK
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：at Customized
• Input Frequency：50Hz,60Hz
• Power Supply：AC 110V,115V,120V,127V,220V,230V,240V
• Transport Package：Plywood Case
• Trademark：Sansion Power
• Origin：Wuhan, China
• HS Code：9030891000
• Production Capacity：100 Sets, Year

Basic Info.

Model NO. SXGK Loading Method Dynamic Load Display Digital Control Manual Control Weight 0-100Kg Power Source at Customized Input Frequency 50Hz/60Hz Power Supply AC 110V/115V/120V/127V/220V/230V/240V Transport Package Plywood Case Trademark Sansion Power Origin Wuhan, China HS Code 9030891000 Production Capacity 100 Sets/ Year

Product Description

Portable High and Low Voltage Circuit Breaker Test Console

General Information:
SXGK Series HV/LV Switch Cabinet Test Bench is mainly applied for ex-work energized testing for high voltage and low voltage cabinet manufacturers. The test bench could provide various AC/DC power source, in order to detect switch cabinet.


Features:
√ Reading directly: Digital meters to display current, voltage, power factor test value.
√ Measuring accurately: High precision, test value is accurate.
√ Full protections: Each circuit is with air switch protection.
√ Portable: Small size, light weight, easy to move.


Main Technical specifications:
√ Input: 3 phase 4 line AC 380V
√ Output voltage and current:
    3 phase AC 0-50A output (10V, adjustable) one group
    3 phase AC 100V output (fixed value) one group
√ AC operating voltage output is AC 0-380V, 220V, the current is conventional and adjustable.
√ DC operating voltage output DC 0-300V adjustable.
√ Single phase AC 220V output (fixed value, plug type) two groups.
√ 3 phase 4 line AC 380V output (fixed value, wiring port) one group.
√ Necessary output units to be increased output protection, and equipped with air switch.
√ Power supply: AC 110V/115V/120V/127V/220V/230V/240V is optional
√Input frequency: 50Hz/60Hz is optional

Please kindly contact with Sansion Power Elctric for details information, we can select correctly designed test system for you.
