High Rate Fast Charge Research Precision Battery Tester with High Capacity Accuracy
Zhengzhou CY Scientific Instrument Co., Ltd.- Type：Lithium Battery Tester
- Test Region：Internal Resistance
- Application：Lithium-ion Battery
- Customized：Customized
- Number of Channels：8chl
- Output Method：Four Electrodes (Support Reference Electrode Test)
Base Info
- Model NO.：G210A
- Way of Communication：10,100m Ethernet(RJ45),RS232(Console)
- Chassis Size：3u W*H*L:430*420*135(mm)
- Transport Package：Standard Export Fumigation Sign Wooden Box Packagi
- Specification：Battery Internal Resistance Tester
- Trademark：CYKY
- Origin：Zhengzhou Henan China
- HS Code：9002209000
- Production Capacity：200
Description
ItemsInstrument indicators Range
Voltage 5V (charge 0~5V, discharge -5V~5V) Current 10A Number of channels 8Chl Precision
Voltage (control and sampling) ±0.01%RD±0.01%FS Current (control and sampling) ±0.01%RD±0.01%FS time ≤±5uS/S (Equipment autonomous control operation, no communication and other time delay errors) input resistance ≥10GΩ Data sampling
Sampling Rate 100Hz Setting method Interval time, sampling frequency Control mode
Operating mode Static / constant current charging / constant voltage charging / rate charging
Constant current discharge / rate discharge Closing condition Time / voltage / current / power / capacity / energy
Number of cycles protection Upper voltage limit, lower voltage limit, overcharge current, over discharge current
Upper limit of charge capacity, upper limit of discharge capacity, overcharge ratio, overshoot ratio
Power failure protection, network protection, and machine protection Feature support DCIR, capacitance calculation, pulse, three-electrode test (reference test), DQ/DV output method Four electrodes (support reference electrode test) way of communication 10/100M Ethernet(RJ45),RS232(Console) Environmental requirements
temperature range 0~40ºC(23±2°C best precision) Humidity range ≤90% without condensation Chassis size 3U W*H*L:430*420*135(mm) Working power AC220V~±10% 50Hz / AC110V~±10% 60Hz, 260W
Product pictures of Single-range precision battery tester:
Founded in 2005, Zhengzhou CY Scientific Instrument Co., Ltd. is a company specializing in the development and production of laboratory technology research equipment. The products are mixed, pressed, burned, cut, ground, polished, coated, analytical equipment and related consumables. Products include laboratory sintering equipment, coating equipment and so on. At present, it has been exported to 25 countries and regions such as the United States, Europe, and Southeast Asia, and has been well received by various scientific research units.
We have a mature technology research and development team, the number of technicians is 33, the company has 150 people, more than 500 square meters of office space, the factory covers an area of about 1,500 square meters located in Zhengzhou High-tech Zone Electronic Industrial Park. The products are mainly located in the research market, serving scientific research in the labs of universities and colleges, and can also customize products according to your needs.
Q. Are you a manufacturer or a trading company?
A. We are professional laboratory instrument manufacturers, have their own design team and factory, have mature technical experience, and can guarantee the quality of products and the optimal price.
Q. How is your company's product after-sales service system?
A. The product warranty period is 12 months, we can provide lifetime maintenance. We have professional pre-sales and after-sales departments that can respond to you within 24 hours to resolve any technical issues.
Q. How long is your delivery time? If I want to customize the instrument, how long does it take?
A.1. If the goods are in stock, it is 5-10 days. 2. We can provide customized services for our customers. It usually takes 30-60 days depending on the specifications of the custom instrument.
Q. Our country's power supply and plug are different. How do you solve it?
A. We can supply a transformer and plug according to your local requirements according to the power plug of different countries.
Q. How to pay?
A.T / T, L / C, D / P, etc., it is recommended to use Alibaba Trade Guarantee.
Q. How is the package of goods? Delivery methods?
A.1. Standard export fumigation sign wooden box packaging 2. Express, air, sea shipping according to customer requirements, find the most suitable way.
More questions, please contact customer service
