• Model NO.：GDBR-P
• Weight：12kg
• Power Source：AC220V
• Current Measurement Range：0 ~ 100A, auto switching range;
• Voltage Measurement Range：0 ~ 600V, auto switching range;
• Frequency Measurement Range：45Hz ~ 55Hz;
• Dimension：400*300*220mm
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030899090
• Production Capacity：1000PCS,Year

Internal source
 Current output: 0-10A
Voltage measurement: 0-10VCapacity10kV Oil-immersed, dry type transformer: 30kVA ~ 2500kVA;
35kV Oil-immersed transformer: 50kVA ~ 31500kVA;
20kV Dry type transformer: 50kVA ~ 2500kVA;
35kV Dry type transformer: 50kVA~2000kVA;No-load and load testVoltage±0.2%FS at 2-100V; ±0.2% at 100-600VCurrentTemperature-5°C-40°CRelative humidity<95% (25°C)Altitude<2500mExternal interference No special strong vibration, no special electromagnetic fieldExternal power supply220VAC±10%, 45Hz~55Hz;
4. Insulation strength

1. Insulation resistance of Voltage and current input terminal to shell ≥100MOhm
2. Withstand voltage between power supply and shell is 2kV RMS, 1mins.
3. Dimension: 400*300*220mm
4. Weight: 6kg. (accessories are not included.)
