Insulation Strength Turn to Turn Surge Withstand Voltage Tester GDZJ-5S

HV Hipot Electric Co., Ltd.
  • Type：Universal Testing Machine
  • Accuracy Grade：1
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control

Base Info

  • Model NO.：GDZJ-5S
  • Weight：24kg
  • Power Source：AC220V
  • Peak voltage：500-5000V continuous adjustment
  • Power supply：220V 50Hz
  • Power consumption：less than 100 W
  • Dimmension：480*260*390mm
  • Transport Package：Carton or Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030332000
  • Production Capacity：2000PCS,Year

Description

Peak voltage500-5000V continuous adjustmentPeak error≤ 5%(1kV-5kV)Waveform rising time0.5μ S or 0.2μ SPower supply220V± 10%, 50HZPower consumption≤ 100 WDimension480*260*390mmWeight24kg
