• Model NO.：GD-H1152
• Heating Method：Heating Tube Heating
• Detection Method：Photocell Detection
• Control Method：Computer Automatic Control
• Working Unit：5 Units
• Power Supply：AC220V 50Hz
• Transport Package：Wooden Case or Plywood
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-H1152 Heating Method Heating Tube Heating Detection Method Photocell Detection Control Method Computer Automatic Control Working Unit 5 Units Power Supply AC220V 50Hz Transport Package Wooden Case or Plywood Origin Made in China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

Automated Mini-rotary Viscometer for measuring low-temperature pumping viscosity from -5C to -40C


Introduction:

The Automated Mini-rotary Viscometer(MRV) is used to determine the borderline pumping temperature, yield stress and apparent viscosity of engine oils at low temperature. The test temperature control range is wide, from -5ºC to -40ºC. The test process is all automatically controlled by a computer.


Main Features:

1. Temperature range: temperature range -5ºC to -40ºC, temperature control accuracy ± 0.1ºC.
2. Fully enclosed compressor refrigeration, large cooling capacity.
3. The temperature, period and rotor motion are monitored by computer.
4. Improved pulley assembly to enhance the stability and sensitivity of the pulley, photoelectric sensor test.
5. 5 rotors can be tested simultaneously.
6. The rotor has a transparent transparent plexiglass cover.
7. Microcomputer control, Windows operating system, full English interface.
8. The program automatically performs temperature control on the nonlinear curve to determine the yield stress and apparent viscosity.
9. Cleaning temperature control and temperature calibration function.
10. Viscometer constant calibration and storage.
11. Test results can be stored and printed.
12. Calculation and printing function of the "air-resistance type" and "flow restricted type" boundary pumping temperature.
13. Equipped with special low temperature thermostat equipment.
14. Equipped with the newly developed defrosting system.


Technical Parameters:
 1. Applicable standards: ASTM D3829, D4684, GB/T 9171 (optional SH/T0562)
2. Refrigeration method: imported compressor refrigeration3. Working temperature: 80~-40ºC4. Temperature control method: program temperature control5. Heating method: heating tube heating6. Detection method: Photocell detection7. Control method: computer automatic control8. Working unit: 5 Units9. Working power supply: AC220V 50HZ
