50A Digital Transformer Winding Resistance Tester (GDZRC-50U)

HV Hipot Electric Co., Ltd.
  • Type：DC Winding Resistance Tester
  • Accuracy Grade：1
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control

Base Info

  • Model NO.：GDZRC-50U
  • Weight：20kg
  • Power Source：AC220V
  • Output current：<5mA, 2.5A, 5A, 10A, 20A, 40A,50A
  • Delivery time：15 working days
  • Mini. resolution：0.1μΩ
  • Accuracy：±(0.2%+2digits)
  • Operation temperature：0~40ºC
  • Humidity：<90%RH (no condensing)
  • Size：400mm×225mm×350mm (L×W×H)
  • Transport Package：Standard Export Wooden Box
  • Specification：325mm*240mm*275mm
  • Trademark：HV Hipot
  • Origin：China(Mainland)
  • HS Code：9031809090
  • Production Capacity：5000sets,Year

Description

Output current

<5mA, 2.5A, 5A, 10A, 20A ,50A

Min. resolution

0.1μΩ

Measurement range

40μΩ~400mΩ

100μΩ~1Ω

500μΩ~2Ω

1mΩ~4Ω

2mΩ~8Ω

5mΩ~20Ω

10Ω~20KΩ

50A

20A

10A

5A

2.5A

1A

<5mA

Accuracy

±(0.2%+2digits)

Operation temperature

0~40ºC

Humidity

<90%RH (no condensing)

Size

400mm×225mm×350mm (L×W×H)

Weight

17kg (without test wire)

test wire box: 3kg
