GDYT-10/100 10kVA 100kV Digital Display PD Free Test Set

HV Hipot Electric Co., Ltd.

Type：Universal Testing Machine
Accuracy Grade：1
Load Way：Electronic Load
Loading Method：Dynamic Load
Display：Digital
Control：Computer Control

Base Info

Model NO.：GDYT-10,100
Weight：0-100Kg
Power Source：AC220V
Rated Capacity：10kVA
Output Voltage：100kv customized
Output Current：100mA customized
Input Voltage：200V
Input Current：50A
Short-Circuit Impedance：≤ 8%
Warranty：1 year
Transport Package：Wooden Case
Specification：ISO, SGS
Trademark：HV Hipot
Origin：Wuhan China
HS Code：9030899090
Production Capacity：2000PCS,Year

Description

Power supply220V±22V,50HZRated Capacity10kVAOutput Voltage100kVOutput current100mA Input Voltage200V, current: 50Ashort-circuit impedance≤ 8%Operation time60mins@100% rated voltage and current.
Continuous working@ 50% rated voltage and current.Wave form distortion rate<5% when voltage regulator input voltage distortion rate <3%, within 10-100% rated voltage rangePD value≤8pC @ 100% rated voltage
≤5pC @ 80% rated voltage

GDYT-10/100 10kVA 100kV Digital Display PD Free Test Set

GDYT-10/100 10kVA 100kV Digital Display PD Free Test Set

GDYT-10/100 10kVA 100kV Digital Display PD Free Test Set

GDYT-10/100 10kVA 100kV Digital Display PD Free Test Set

GDYT-10/100 10kVA 100kV Digital Display PD Free Test Set
