Universal Joint Drive Dynamic Balancing Machine Price
Dongguan Hongjin Test Instrument Co., Ltd.- After-sales Service：Lifetime Maintenance
- Warranty：1 Year
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Balancing Machine
- Maxcapacity：<1000KN
Base Info
- Model NO.：HJ-80
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Digital
- Weight：0-100Kg
- Power Source：AC220V
- Silicon Steel Sheet Stacking Thickness：15-60mm
- Rotor Diameter：23-60mm
- Rotor Shaft Diameter：2.0-12mm
- Transport Package：Fumigation-Free Standard Export Wooden Box
- Trademark：Hongjin
- Origin：China
- Production Capacity：1000 Sets, Month
Description
Basic Info.
Model NO. HJ-80 Accuracy Grade 0.5 Load Way Electronic Load Loading Method Static Load Display Digital Weight 0-100Kg Power Source AC220V Silicon Steel Sheet Stacking Thickness 15-60mm Rotor Diameter 23-60mm Rotor Shaft Diameter 2.0-12mm Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ MonthProduct Description
Application range:Mainly used in the balance calibration of large and medium-sized motor rotors, blowers, centrifugal impellers, wheels, dryers, drums and other rotating workpieces.
This machine adopts universal coupling or gear box transmission, and can obtain various balanced speed or stepless speed regulation, and has the characteristics of large driving power, high precision and convenient operation.
Product Features:
The universal joint balancing machine has a reliable design and uses an industry-leading measurement system. Dynamic and static balance, there are up to 10 kinds of support modes, plus de-weighting, forward and reverse rotation can be flexibly customized, the balance amount and angle unit of the measurement display can be customized, and the displayed precision can also be customized arbitrarily, realizing real-time conversion of units to meet the needs of Different customer needs.
| Silicon steel sheet stacking thickness | 15-60mm |
| Rotor diameter | 23-60mm |
| Rotor shaft diameter | 2.0-12mm |
| Measuring rotational speed | 2100RMP |
| Milling method | Select knife type according to rotor unbalance |
| Power supply | AC220V/50Hz |
| Gas source | 0.4-0.6Mpa |
| Work beat | (detection, milling once on each side) 8-16 seconds |
| Residual Unbalance Accuracy | National standard 6.3 |
| Correct number of rotors per hour | 200 or so |
