Asphalt Rtfot Rolling Thin-Film Oven for Rolling Thin Film Oven Test
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Transport Package：Wooden Case or Iron Case
- Trademark：GOLD
- Origin：China
Base Info
- Model NO.：GD-0610
- HS Code：9031809090
- Production Capacity：100sets,Month
Description
Basic Info.
Model NO. GD-0610 HS Code 9031809090 Production Capacity 100sets/MonthProduct Description
Asphalt RTFOT Rolling Thin-Film Oven for ROLLING THIN FILM OVEN TESTIntroduction:
The Asphalt RTFOT Rolling Thin-Film Oven is designed and made as per industrial standard T 0610-2011 and ASTM D2872 Standard Test Method for Effect of Heat and Air on a Moving Film of Asphalt in JTG E20-2011 Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering.
The Asphalt RTFOT Rolling Thin-Film Oven is suitable to determine mass loss of highway asphalt rolling thin film after heating, and the change of penetration, viscosity, ductility and breaking point of asphalt residue after the thin film has been heated, so as to estimate the aging performance of bitumen.
Features:
1. The Asphalt RTFOT Rolling Thin-Film Oven is composed of electric control component, working oven and mechanical drive. An illuminating light is equipped in the oven for convenient observation.
2. There is an air compressor in the oven to supply the air needed for the test. The air can be controlled by a flowmeter on the panel.
3. The Asphalt RTFOT Rolling Thin-Film Oven adopts high precise temperature controller which can meet test requirements.
Specifications:
1. Power supply: AC(220±10%)V, 50Hz
2. Heating power: 2.4kW
3. Working temperature: 163ºC
4. Temperature control precision: ±0.5ºC
5. Rotating speed of turn plate: (15±0.2) r /min
6. Air flow rate: (4000±200)mL /min
7. Timing unit: Alert at 85 min
8. Ambient temperature: (5~50)ºC
9. Relative humidity: ≤85%
10. Maximum power consumption: 2.6kW
Welcome to visit us!
Contact us!
Notes:
1,The reagent and equipments for installing the instrument are supplied by end-users themselves.
2,The usage,management and saving of poisonous and harmful reagent,pls operate according to the relative principle.
3,PLS read the operation manual and industry standard before using the instrument.
