• Model NO.：HTPV-11A
• Function：Detecmine The PV Module′s Insulation Performance
• Product Name：Solar PV Module Insulation Resistance Tester
• Delivery：20 Days
• Transport Package：Wooden Case
• Trademark：HOTOTECH
• Origin：Dongguan
• HS Code：9013809000
• Production Capacity：50PCS

Basic Info.

Model NO. HTPV-11A Function Detecmine The PV Module′s Insulation Performance Product Name Solar PV Module Insulation Resistance Tester Delivery 20 Days Transport Package Wooden Case Trademark HOTOTECH Origin Dongguan HS Code 9013809000 Production Capacity 50PCS

Product Description

Solar PV Module Insulation Resistance Tester

Technical parameters:

1, Insulation resistance and leakage current double parameters test.

2, Insulation resistance measurement range: 100 k-10 T Ω (105 ~ 1013 Ω )

3, Insulation resistance basic accuracy: < 1 G: 1%, 1 G: 3%, frequency quartile

10 G: 5%, 1 T: 10% frequency.

4, Output any load voltage: 1.0 VDC ~ 1000 VDC, < 100 V: Voltage stepping Measures 0.1 V, frequency 100 V: Voltage step 1 V amount. Basic accuracy: 1%

5, Maximum charge current: 30 mA ± 5 mA.

6, Six range to be automatic or manual testing.

7, Three gears test speed: High speed 55 times/SEC, medium-speed: 25 times/SEC, full speed: Three times/SEC.

8, The built-in accurate timer, custom charging time, regularly time: 0 SEC-999.9 seconds.

9, Double show: Shows leakage current, absolute deviation (Δ ABS)relative Deviation (Δ %) and separation output results (GD/NG) at the same time

10, A variety of trigger way: Internal trigger, manual trigger, external trigger and Remote triggered.

Performance characteristics:

1. High brightness, super clear four color VFD display, various parameters shows At the same time.

2. The open range reset function.

3. The comparator (sorting) function: Built-in group of 30 records, can be measured on a GD/NG judgment.

4. The comparator output: Through the optional RS232C output interface, Handler sorting results.

5. The ring can be set the switch.

6. Ring and display adjustable

7. The built-in RS232C serial interface.

8. Optional Handler interface.

9. Compatible SCPI programming standards

10. Optional pedal switch.
