• Model NO.：QT-6508A
• Display：Needle
• Control：Manual Control
• Weight：20kg
• Power Source：AC220V
• Tape：Kinds of Adhesive Tapes
• Material：Stainless
• Transport Package：Wooden Case
• Specification：850*250*580mm
• Trademark：SUZHOU QIANTONG
• Origin：Jiangsu, China
• HS Code：9024800000
• Production Capacity：423 Set

Basic Info.

Model NO. QT-6508A Display Needle Control Manual Control Weight 20kg Power Source AC220V Tape Kinds of Adhesive Tapes Material Stainless Transport Package Wooden Case Specification 850*250*580mm Trademark SUZHOU QIANTONG Origin Jiangsu, China HS Code 9024800000 Production Capacity 423 Set

Product Description

1. Qiantong main scope of testing machineElectronic universal material testing machine, Horizontal tension testing machine, Hydraulic universal testing machine, MFI, Charpy Impact, Izod Impact, HDT-Vicat tester, Hardness tester, Torsion tester, Metallographic series, Oven and so on. (We accept customization.)2. Product Brief:Attach tape to the test board, the lower end hangs the standard load. After a period of time, the distance of the tape to slide or the time of the tape sticking are measured to evaluate the durability of the tape sticking.

Meeting standard:GB/T 4851-1998  CNS 11888-2008  JIS C 2107-2011 QB/T2424-98   GB/T3280-1992    ASTM D3654-066

Process:Pressure sensitive adhesive tape adhesive products for viscosity test, the test board attached to the sample vertically hanging on the test rack, the lower end of the suspension of the specified weight of the weight, with a certain time after the displacement of the sample viscosity or the time of the sample completely released to test the adhesive tape resistance to the ability to pull out
 3. Technical specifications

Type	QT-8301	QT-8301A	QT-8301B	QT-6508A
testing fixture	5 groups	10 groups	30 groups	20 pieces
testing weight 1kg	5 pieces	10 pieces	30 pieces	20 pieces
timer	5 groups  999999 min	10 groups  999999 min	30 groups  999999 min	20 groups;  999999 min
stainless steel plate	SUS #304, 5 pieces	SUS #304, 10 pieces	SUS #304, 30 pieces	SUS #304, 20 pieces
connector	5 pieces	10 pieces	30 pieces	20 pieces
Temperature	RT	RT	RT	CT
auxiliary accessories (1 piece)	Gradienter pinch roller	Gradienter pinch roller	Gradienter pinch roller	Gradienter ; observation window;pinch roller
size(W×D×H)mm	850×250×680	850×250×580	850×250×580	900×550×750
weight	20kg	38kg	58kg	80kg

Some cooperative brands(This ranking is in no order)
