Smoothness Tester for Paper or Cardboard with Bekk Method
Hangzhou Pnshar Technology Co., Ltd.- Type：Paper Smoothness Testing Machine
- Load Way：Electronic Load
- Display：Touch Screen
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
Base Info
- Model NO.：PN-BST
- Transport Package：Seaworthy or Airworthy Package
- Specification：ISO, ASTM, TAPPI
- Trademark：PNSHAR
- Origin：China
- HS Code：90248000
- Production Capacity：100sets,Month
Description
Basic Info.
Model NO. PN-BST Transport Package Seaworthy or Airworthy Package Specification ISO, ASTM, TAPPI Trademark PNSHAR Origin China HS Code 90248000 Production Capacity 100sets/MonthProduct Description
1. INTRODUCTION:This is Smoothness tester for paper or cardboard with Bekk method.
Smoothness tester for paper or cardboard with Bekk method is a new type tester developed by our company according to the ISO standards. This instrument is mainly used to test the smoothness of the paper or cardboard (by Bekk method). Bekk smoothness: Time in seconds which under a defined pressure differential is required to draw a definite quantity of air at atmospheric pressure between the surface of the test piece and a ring-shaped plane surface under specified conditions of contact. The smoothness of a wide range of paper and boards may be measured by this method and it is especially recommended for smooth papers and boards. However, for very smooth samples, measurement times may be impractically long.
2. APPLICATIONS:
Paper. Paperboard.
3. STANDARDS:
ISO 5627
| NO. | ITEM | SPECIFICATION |
| 1 | Power supply: | AC220V±10% 50HZ |
| 2 | Precision: | 0.1s |
| 3 | Measuring range: | 10±0.05cm2 |
| 4 | Pressure: | 100kpa±2kpa |
| 5 | Display: | English menu and LCD screen |
| 6 | Printer : | thermal printing, high speed and no noise. |
| 7 | Communication output: | standard RS232 interface |
| 8 | Ambient conditions: | temperature 10~30 degree. Relative humidity<85% |
| 9 | External dimensions and weight: | Length × Width × Height: ?318mm×362mm×518mm, 35kg |
