• Model NO.：GDOT-100D
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Top
• Capacity：1.5kVA
• Output voltage：100kv
• Delivery time：7 working days
• Transport Package：Wooden Box
• Specification：430 mm*350 mm*370 mm
• Trademark：HV Hipot
• Origin：China(Mainland)
• HS Code：9030899090
• Production Capacity：5000sets,Year

Basic Info.

Model NO. GDOT-100D Weight 0-100Kg Power Source AC220V Oil Cylinder Position Top Capacity 1.5kVA Output voltage 100kv Delivery time 7 working days Transport Package Wooden Box Specification 430 mm*350 mm*370 mm Trademark HV Hipot Origin China(Mainland) HS Code 9030899090 Production Capacity 5000sets/Year

Product Description

GDOT-100D 100kV 3 Cups Insulation Oil Breakdown Voltage Tester

Description

In power system, railway system and large petrochemical industrial enterprises all have
a lot of electrical equipment, its internal insulation is mostly oil-filled insulation type.
Dielectric strength test for insulating oil is a routine test which shall be measured.
In order to meet the market needs. Our company self-developed and produced
GDOT series dielectric strength tester for insulation oil according to national standard
GB/T5072002, industrial standard DL429.991 and the latest electric power industry
 DL/T846.7- 2004 standards.
The instrument use single chip microcomputer as the core, to achieve full automatic testing and high precision measurement, greatly improves the work efficiency,
also reduce the labor intensity of the workers.



Features

• With microprocessor, three cups in one, automatically complete boosting, holding, stirring, static releasing, calculation and printing.
• Enable to carry out oil circulating withstand voltage test in the range of 0-100KV.
• Large screen LCD display.
• Simple to operate, automatically complete 1-3 oil samples withstanding voltage test according to the settings. Each oil sample will be automatically stored for each breakdown voltage value and cycle number. After the test is completed, the thermal printer can print out the breakdown voltage value and average value of each oil sample.
• This series has strong applicability, not only can be used in laboratories, but also be used in outdoor fields. The instrument also has strong anti-interference ability and can work normally in strong electromagnetic field environment. It is very suitable for use in departments with more oil samples and tight test time.
• With over-voltage, over-current, zero return protective function, it can ensure the safety of operators and device at normal use.
• Increasing speed can be set according to different test standard.

Specifications


Output voltage	0-100kV
Power distortion rate	<3%
Voltage increasing speed	2.0,2.5,3.0,3.5kV/s (adjustable)
Voltage measurement error	±3%
Capacity	1.5kVA
Power input	AC220V± 10%, 50Hz±1Hz
Power	<200W
Working temperature	0ºC-+40ºC
Oil cup volume	200mL (400mL optional)
Electrode spacing	2.5mm
Humidity	<80%RH
Dimension	470*430*480mm
Weight	49 kg
