• Model NO.：HJ-68
• Weight：0-100Kg
• Power Source：AC220V
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-68 Weight 0-100Kg Power Source AC220V Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Features of Rotorless vulcanization testing machine

a. High temperature control accuracy and wide range. (±0.1ºC)

b. Clock programming function. (setting, modification time)

c. Advanced switching power supply with wide voltage regulation range.

d. Imported integrated circuits and control components.

e. All in Chinese and Chinese.

f. Meet the requirements of GB/T16584 (testing rubber vulcanization characteristics with a rotorless vulcanizer) and ISO6502.

Parameters of  Rotorless vulcanization testing machine



The implementation standard of the vulcanizator is	ASTMD5289-95 ISO6502-1999 (E) GB/T16584-1996
Temperature measurement range	Room temperature--200ºC
Temperature measurement accuracy	100--200ºC,≤±0.1ºC
Temperature control stability	100--200ºC,≤±0.1ºC
Predetermined area	0--200ºC; set minimum unit: 0.1ºC
Temperature display range	0--200ºC; Display resolution: 0.1ºC
Set the time range;	0--200 minutes
Set the minimum unit	1 minute
Automatic range switching	Automatically increase according to the actual torque
Power supply	50HZ, ~220V±10%, 50±1Hz, must be well grounded
Compressed air	0.32Mpa controlled by pneumatic regulating valve
Swing frequency	100 times/min (about 1.7HZ)
Ambient temperature	Normal temperature--40ºC, relative humidity less than 80%, no corrosive gas in the air
Quality	≈250kg
Power	2KW
Dimensions	680×630×1100(mm)

The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.


FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
