• Model NO.：GDDO-20T
• Oil Cylinder Position：no
• AC voltage range：50V, 100V, 200V, 400V, 600V;
• AC current range：0.5A, 1A, 2.5A, 5A, 10A, 20A;
• Adjustment range of AC voltage and curre：0~130% FS, fineness adjustment: 5×10-5
• Active power：50~400V, accuracy: 0.05%FS
• Reactive power：50~400V, accuracy: 0.1%FS
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HVHIPOT
• Origin：Wuhan China
• Production Capacity：1000PCS,Year

AC voltage range

50V, 100V, 200V, 400V, 600V; Max. output capacity: 20VA

AC current range

0.5A, 1A, 2.5A, 5A, 10A, 20A; Max. output capacity: 20VA

Adjustment range of AC voltage and current

0~130% FS, fineness adjustment: 5×10^-5

Accuracy of power frequency AC voltage and current

0.05% FS

Active power

50~400V, accuracy: 0.05%FS

Reactive power

50~400V, accuracy: 0.1%FS

Phase accuracy of current to same phase voltage

0.050

Frequency

adjustment range: 45~65Hz, fineness adjustment: 0.001Hz, accuracy of setting value: 0.01Hz

Phase

adjustment range: 0~359.99°, fineness adjustment 0.01°

Power factor

adjustment range: 0~±1, fineness adjustment: 0.0001, accuracy of setting value: 0.0005

Waveform distortion of AC voltage and current output

≤0.3%

Stability of AC voltage, current and power output

≤0.01% FS /60s

 Harmonic

2nd~31th, amplitude: 0~40%, phase fineness of each harmonic: 0.010·N(N refers to harmonic order)

DC voltage range

75mV, 75V, 150V, 300V, 500V, 1000V, Max. output capacity: 20W

DC current range

0.5A, 1A, 2.5A, 5A, 10A, 20A, Max. output capacity: 20W

Adjustment range of DC voltage and DC current

0~120%FS (For 1000V: 0~105% FS), fineness adjustment: 5×10^-5

Accuracy of DC voltage and DC current output

≤0.01% FS /60s (Peak-peak)

Setting value accuracy of DC voltage

0.05%FS

Setting value accuracy of DC current

0.1%FS

Accuracy of DC output (at 75mV, load ≥5Ω)

0.1%FS

DC measurement accuracy(for transmitter output and measurement)

0.02%FS (Voltage: 0~±24V, current: 0~±24mA)

Comprehensive error of electricity meter measurement (50~400V)

0.05%(Pulse output: three phase rated value=6Hz)

Power supply

single phase 220V±10%, 50Hz±5%

Use conditions

20ºC±10ºC, ≤85%RH

Size

460*460*175mm

Weight

20kg (Upgraded version 24kg)
