• Model NO.：HJ-1
• Weight：0-100Kg
• Power Source：AC220V
• Height Range：300~1500mm
• Drop Area：1200X1100mm
• Floor Area：1200X1700mm
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-1 Weight 0-100Kg Power Source AC220V Height Range 300~1500mm Drop Area 1200X1100mm Floor Area 1200X1700mm Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Introduction:
During the products handling or transport process, there may be drop/ fall, which results in damage within the products. And this device simulates the drop/ fall of a finished product to evaluate the damage. All the rhombohedrons, angles and faces of the products can be tested.. With digital height indicator and adopt decoder to track , which can give accurate product drop height, and the default drop height error does not exceed 2% or 10mm. The machine adopts single-arm double-column structure, with electric reset, electric control and electric lifting devices drop, easy to use; Arm set, you can easily place the product.

Features
This testing machine is designed to simulate and test the internal damage of various products when they are dropped during handling or transportation after being packaged, so as to obtain the best solution to minimize losses during transportation. ; This testing machine can test the diamond, angle and surface of the packaging container.

Standards compliant
ISO2248 JISZ0202-87 GB/T4857.5-92

Height range	300~1500mm
Drop area	1200X1100mm
Floor area	1200X1700mm
Specimen allowable size	L850XW750XH1600mm
Bearing weight	About 50 Kg
Highly debugged	Motor driven (digital display can be set)
Horsepower	1/3hp
Working power	380V 50Hz 10A
Control box size	L420X W230XH680mm

FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
