Komeg Walk-in Environmental Constant Temperature Humidity Stability Climatic Test Chamber
Guangdong Komeg Industrial Co., Ltd.- Power Supply：380V
- Certification：CE, ISO
- Warranty：1 Year
- Chamber Size：as Per Requested
- Brand：Komeg
- Transport Package：Plywood Case
Base Info
- Model NO.：KMHW
- Specification：CE, SGS
- Trademark：KOMEG
- Origin：China
- HS Code：90321000
- Production Capacity：1000 Sets,Year
Description
Walk-In ChambersSPECIFICATIONS Note: We reserve the right to change specifications without prior notice Model KMHW- 4 6 8 13 17 21 Volume(m ³ ) 9 12.9 16.8 16.8 35.2 13.3 Interior Dimensions W(mm) 2100 3000 3900 3000 3900 4800 H(mm) 2100 2100 2100 2100 2100 2100 D(mm) 2050 2050 2050 4300 4300 4300 Exterior Dimensions W(mm) 3250 4160 5050 5050 5050 5950 H(mm) 2350 2350 2350 2350 2350 2350 D(mm) 2250 2250 2250 2250 4500 4500 Safety Devices(standard) No fuse breaker, over pressure over heat and over current protection for compressor,over temperature protection,
over load protection for blower, dry heat protection Standard accessories Sight window*1,cable port(portΦ50mm)*1,chamber lamp*1, status indicator Control System Balanced Temperature & Humidity Control System Refrigeration system Water Cooled Semi-hermetic compressor, single stage or cascade refrigeration system, CFC free refrigerant ( HFC-507 and HFC-23 ) Controller Panel 7-inch LCD Touch panel , Chinese or English display selectable Operation model Program or fix point running Memory capacity 120 programs,1200steps, all repeat 999 cycles , part repeat 99 cycles Accuracy Temp.:0.1% of F.S±1 digit Humidity:0.1% of F.S±1 digit Input Temp.:pt-100, Humidity:pt-100 or ~ 5V DCV Comm.port RS-232 or RS-485 (Softawre is option) Temp. range Maximum : 80 ºC, 120 ºC; Minimum : -60 ºC, -50 ºC, -40 ºC , -30 ºC, -20 ºC , -10 ºC, 0 ºC Humidity Range 10 %, 20% , 30% ~ 95% Temp. constancy ±0.5 ºC Humidity constancy ±2.5 % R.H Temp. uniformity ±2.0 ºC Humidity uniformity ±5.0 % R.H Ambient Temp. +5 ºC~ +35 ºC Wiring method AC 380±10 % 50Hz ,3 phase 4 wires +Ground Wires Heat up time +20 ºC~ +80 ºC ,Within 60 min Pull down time +20 ºC~ -55 ºC -40 ºC -20 ºC -10 ºC ,Within 120 or 90 or 60 min Interior material Stainless Steel Plate(SUS 304) Exterior material Baked Painting Steel Or Stainless steel(SUS304) Insulation material Rigid polyurethane foam Door size (mm) Single wing : W800*H1800 ; Double wing : W1600*H1800 ; Note:1. We reserve the right to change specifications without prior notice 2.Customized sizes and configurations available
