• Model NO.：ESS-225S
• Trademark：KOMEG
• Origin：China
• HS Code：90321000
• Production Capacity：6000PCS,Year

TemperatureTemperature Range-70ºC ~ +150ºCTemperature Deviation<=±2.0ºCTemperature fluctuation±0.5ºCTemperature Uniformity<=2.0ºC

Temperature Heating and

Cooling Rate

Heating rate: -40ºC to +120ºC Linear 5ºC/min no-load

Cooling rate: +120ºC to -40ºC Linear 5ºC/min no-load

HumidityHumidity range20%R.H~98%R.HControl range



Humidity deviation

±3.0%RH(>75%RH)

±5.0%RH(≤75%RH)

Humidity uniformity±3.0%RH(no-load)Humidity fluctuation±2.0%RHTemperature change rate designed according to IEC 60068-3 standard, Sensors in the outlet and products. Chamber StructureOverall structure and chamber was composed of three parts as below. Insulation box, separate refrigeration units, and electrical control cabinet.Chamber

Workspace volume: W 700 × H 700 × D 480 mm

Exterior size: approximately W 1000 × H 1735 × D 2030 mm (not including the machine protruding par)

Insulation

 wall material: high-quality carbon steel with static color spray

 inner wall material: SUS304 # matte stainless steel plate

 Insulation materials: rigid polyurethane foam insulation layer + glass fiber.

DoorSingle door. Heating wire was installed at the door frames to prevent condensation at low temperatures.Observation WindowObservation Window (W460*H560mm)on the door, with multi-layers of electric painted heat hollow glasses to avoid condensation.Lighting device1 LED lighting device located on observation window.HeatingHigh-quality nickel-chromium alloy wire heater, non-contact control mode (SSR). Humidifying

Steam heating and humidification method;

Stainless steel sheathed heater;

Heater control: contactless control (SSR);

Water level control device, heater anti-dry device.

Water outlet holeAvailable for drain the condensate waterThread portDiameterφ100mm port on the left chamber with rubber isolation plug and plastic coverSample holderOne layers of stainless steel sample holder.Layer height adjustable, Bearing weight 30kg/ layerMobile castersInclude mobile casters (with goblet)Electric control boxTotal power circuit breaker, over-temperature protection.

12.Water supply

system

Water pump automatic supply

FAQ:

How long will it take from order placement to goods delivery?

For standard environmental chambers, we have semifinished products and finished products, the delivery

time is about 15days.For non-standard environmental chambers, the delivery time is about 45~50 days.

Do you have any advantages in your price?

KOMEG production bases in Dongguan songshan lake district. At present it is the largest scale producer

in environmental test chamber filed. We are looking forward to long term cooperation business

relationship with customer, with the idea for small profits but quick turnover, customer will get the most

competitive price from our factory headquarters directly.

How many certifications do you have ?

We have passed the CE certification, the ISO certification and certification etc.

May I ask you how do you deliver these products?

We have several ways of delivery, such as FOB, CIF, DDP etc.

Which countries have your product sold to?

We have sold to so many countries, such as Russia, America, Korea, Denmark, Vietnam, Thailand,India,

Singapore, Pakistan, Turkey, German, England and other more than 40 countries.

How long the warranty of your environmental chambers covered?

We provide free parts replacement service for accessories with one year.

What solutions will you provide if your products break down ?

We will give you guidance through video conference/picture when we receive your notice of repair. If

necessary, we could also send our engineers to your country for troubleshooting.

How to install and use the product?

The product is shipped with an operating instructions and video of English version.For large walk in test

chamber that can't be put into the container, we will dismantled it first and send our engineer for

installation



After-sale Service:

If you face any problems in future during testing process we promise we will give you a reply within 48

hours and solution provide within 3 working days. We can offer operation video and English operation

muanual. We can provide video-conference. If customers require on-site service, the transport and travel

expense shall be borne by customer.



Packing Details:

We use PP Film wrapping the test chamber to protect the test chamber from moisture or being scratched

first, then use strong plywood case for easyload and transport, and to keep the chambers from potential

crash or impact.
