• Model NO.：HJ-56
• Loading Method：Static Load
• Display：Digital
• Weight：0-100Kg
• Power Source：AC220V
• Counter：6 Bits (Built-in)
• Voltage：220V
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-56 Loading Method Static Load Display Digital Weight 0-100Kg Power Source AC220V Counter 6 Bits (Built-in) Voltage 220V Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Product introduction:
one. Overview
1. The mobile phone wire swing tester is a device that tests the reliable performance of the mobile phone earphone wire under the rated tension (2N) of repeated 180° swing.
2. The structure design is reasonable and unique, and it has full applicability to different types of mobile phone wires.
3. The equipment runs stably, with low noise and maintenance-free.
two. Testing purposes
1. Fatigue resistance at the headphone plug wire connection.
2. The effect of wire swing on the headset.
three. Test procedure description
The test is performed by simulating the reciprocating swing of the earphone wire during the user's use.
Manually clamp one end of the earphone wire in the fixed end fixture, and the other end is fixed in the fixed card at the front end of the stretching cylinder → the stretching cylinder action provides 2N pulling force for the wire → the swinging cylinder action drives the headphone wire to swing left and right.
Four. Function realization
1. The cylinder provides the pulling force; the cylinder realizes the action; PLC control.
2. Large touch screen interface control.
3. Manual and automatic switching.

Number of workstations	1/set
Operation method	Touch screen
Action actuator	SMC standard cylinder, rotary cylinder
Pull	2N (adjustable)
Wobble frequency (beat)	1~30 times/min (adjustable)
Counter	6 bits (built-in)
Voltage	220V;
Power	100W
Air pressure	0.05~0.6Mpa
Dimensions	600×560×700mm
Weight	40kg

   FAQ    1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2..What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.

3. Do you accept customization service? Can I have my logo on the machine?Yes, of course. We can not only offer standard machines, but also customized
machines according to your requirements. And we can also put your logo on the machine.
