• Model NO.：GDYD-11D
• Power Supply：AC220V±10%, 50Hz
• Capacity：1kVA
• Output voltage：AC 0-10kV DC 0-14kV
• Rated output current：5A
• Rated current rectified range：0-5A
• HV voltmeter range：0-10kV
• HV ammeter range：0-100mA
• LV ammeter range：0-5A
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030332000
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GDYD-11D Power Supply AC220V±10%, 50Hz Capacity 1kVA Output voltage AC 0-10kV DC 0-14kV Rated output current 5A Rated current rectified range 0-5A HV voltmeter range 0-10kV HV ammeter range 0-100mA LV ammeter range 0-5A Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/Year

Product Description

I. General information

GDYD-11D AC/DC Hipot Test Set is compact unit which integrate control unit with HV unit in one device. It is suitable for electric power branch, power department of factories, scientific research units, railway, chemical industry, power plants.


II. Features

1. Digital display meters mounted on the panel.
2. Monitoring HV side voltage, HV side current, LV side current and indicator of zero, power, working start, timing.
3. Over-current protection, zero-starting protection, sound and light alarm.
4. With new type time relay, time rang is more wider (1S ~ 99H).
5. Using the latest current relay, more accurate and reliable.
6. Light weight, small size, easy to move.


III. Specifications


Power input	AC220V±10%, 50Hz
Capacity	1kVA
Output voltage	AC 0-10kV  DC 0-14kV
Rated output current	5A
Rated current rectified range	0-5A
HV voltmeter	Range: 0-10kV Accuracy: 1.5% of the reading±1digit(F.S)
HV ammeter	Range: 0-100mA Accuracy: 1.5% of the reading±1 digit(F.S)
LV ammeter	Range: 0-5A Accuracy: 2.0% of the reading±1 digit(F.S)
Timing range	1s-99h
Weight	36kg
Dimension	470mm (L)*345mm (W)*515mm (H)
Working conditions	1. Working place: No gas, steam, chemical dust and explosive and corrosive medium which will influence insulation. 2. Environment temperature: -20--50ºC 3. Environment humidity: ≤85% RH (no condensing)
