Htxz-75kVA/75kv AC Variable Frequency Resonance Test Series Resonant Test System for Cable Hipot Dielectric Withstand Voltage Test
Wuhan UHV Power Technology Co., Ltd.- After-sales Service：Hv Cable
- Warranty：1 Year
- Connectors：USB
- Test Mode：Instant Test
- Usage：Digital Cable Tester
- Test Region：Forming Cable
Base Info
- Model NO.：HTXZ
- Cable Type：Hv Cable
- Power：Electricity
- Certification：CE, RoHS, ISO
- Customized：Customized
- Color：Red
- Rated Output Voltage：≤0~50kv(AC Effective Value)
- Output Frequency：45~65Hz
- Resonate Voltage Waveform：Sine Wave, Distortion ≤1%
- Working Mode：Full Power Continuous Working Time: 5min
- Quality Factor：10~40
- Maximum Measured Capacity：0.1Hz, Instability<0.05%
- Power Supply：≤5000kVA
- Output Voltage：220vor 380V±10%, Frequency :50Hz±5%
- Model：100,50, 150,50, 225,50, 350,50
- Divider：50kv,500PF
- Reactor：50kv,1A, 50kv,1.5A, 60kv,2A
- Colour：Red
- Cusotmer：Cusotmezed
- Certificate：CE,ISO
- OEM：Ok
- Transport Package：Wooden Case
- Specification：see details
- Trademark：HV TEST
- Origin：China
- HS Code：9030899090
- Production Capacity：60 Sets Per Month
Description
