• Model NO.：SXCF
• Power Source：380V,220V110V at Cutomized
• Nominal Voltage：200kv or at Customized
• Rated Energy：10kj or at Customized
• Impulse Capacitance：0.5UF or at Customized
• Each Stage：100kv 0.25UF or at Customized
• Transport Package：Plywood Cases
• Trademark：Sansion Power
• Origin：Wuhan, China
• HS Code：9030339000
• Production Capacity：100 Sets, Year

Basic Info.

Model NO. SXCF Power Source 380V/220V110V at Cutomized Nominal Voltage 200kv or at Customized Rated Energy 10kj or at Customized Impulse Capacitance 0.5UF or at Customized Each Stage 100kv 0.25UF or at Customized Transport Package Plywood Cases Trademark Sansion Power Origin Wuhan, China HS Code 9030339000 Production Capacity 100 Sets/ Year

Product Description

200 KV / 10 KJ High Voltage Impulse Voltage Generator

System instruction Main Parameters for System



1. Nominal voltage: ±200kV



2. Rated stage voltage: ±100kV



3. Rated energy: 10kJ



4. Impulse capacitance: 0.5µF



5. Number of stages: 2



Rated stage capacitance: 1µF(each impulse capacitor 1µF at 100kV, total 2pcs)



Impulse voltage waveform: generated when load capacitance is 300-3000pF.

T1=1.2µs±30%, T2=50µs±20%, standard lightning impulse voltage full waveform of peak voltage deviation≤3%;
Standard operation waveform 250±20%/2500±60%. These 2 Impulse voltage waveform parameters and error are accorded with national requirements of IEC standard.

1. Voltage utilization factor: Standard lightning impulse voltage waveform ≥90% when load capacitance is below 1000pF, standard operation impulse voltage waveform≥80% when load capacitance is below 2000pF.

2. Standard operation impulse voltage waveform ≥70%.

3. Locking range: level voltage is within the range of 20%-100% rated voltage, positive and negative locking range no less than 25%.

4. Out-of-control rate of synchronous discharge: <5%

5. Min. output voltage: ≥±20% of rated voltage.

6. Instability of discharge voltage: <±1.0%

7. Continuous time: Above 2/3 of rated voltage, continuous working when charge and discharge once every 120s. Below 2/3 of rated voltage, continuous working when charge and discharge once every 60s.
More details please contact Sansion Power by email for further information.
