• Model NO.：HYXY-170
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Oil Cylinder Position：No
• Transport Package：Wooden Case
• Specification：900mm*W700mm*H1800mm
• Trademark：C-TECH
• Origin：China Mainland
• HS Code：90248000
• Production Capacity：100 Set, Month

Basic Info.

Model NO. HYXY-170 Control Computer Control Weight 100-500Kg Power Source AC220V Oil Cylinder Position No Transport Package Wooden Case Specification 900mm*W700mm*H1800mm Trademark C-TECH Origin China Mainland HS Code 90248000 Production Capacity 100 Set/ Month

Product Description

High efficiency Asphalt Mixture gyratory compactor

This gyratory compactor is used to simulate and reproduce the real compaction conditions under actual road paving operations , hence determining the compaction properties of the asphalt .

The compactor comprises a highly rigid steel frame ensuring excellent angle control
Load is applied by an electro-pneumatic cylinder , servo-controlled by a precision pressure regulator ;The height is measured by a linear transducer


MAIN FEATURES:
- Highly rigid steel frame ensuring excellent angle control, to meet the strict tollerances requested by EN Specifications.
- Electro-pneumatic action with servo-controlled regulator.
- Electronic control unit with touch screen color display, that runs like a standard PC based on Windows operating system.
- Software for acquisition and PC data processing.
The touch-screen icon interface allows an easy set up of the parameters and immediate automatic execution of the test, data acquisition,processing, graphics and file.
Direct connection to Intranet (connection to a LAN network) and Internet to establish a remote communication and receive an immediate.
Diagnostic analysis of the potential problem from Matest technicians, or for software updates.
Unlimited memory storage with:2 USB ports, 1 SD card


Displacement Range:	0~250mm.
Specimen height range :	30-170mm
Rotary compacting displacement accuracy:	<0.10mm
Rotation Angle :	0°~2°±0.02° adjustable,
Vertical load:	0~1000Kpa adjustable,
Rotation speed :	0-50r/min adjustable
Number of gyratory:	:0~999
Mould:	Ø150mm,(ø100mm can be custom )
Pressure on the way :	Pneumatic
Ouside size:	L900mm×W700mm×H1800mm.
