• Model NO.：GD-0059B
• Pressure Accuracy：Resolution Accuracy 0.05 mm H2O
• Stability Precision：0.2 mm H2O
• Total Consumption：Less 2200W
• Transport Package：Wooden Case for Automatic Noack Evaporation Loss T
• Trademark：GOLD
• Origin：China
• Production Capacity：100 Sets, Month

Basic Info.

Model NO. GD-0059B Pressure Accuracy Resolution Accuracy 0.05 mm H2O Stability Precision 0.2 mm H2O Total Consumption Less 2200W Transport Package Wooden Case for Automatic Noack Evaporation Loss T Trademark GOLD Origin China Production Capacity 100 Sets/ Month

Product Description

Automatic Noack Evaporation Loss Tester ASTM D5800 for Lubricating Oils


This Noack evaporation loss tester is designed and made as per ASTM D5800.
ASTM D5800 standard test method is for testing evaporation loss of lubricating oils by the Noack B method.


I.Summary
  The Noack evaporation loss tester is designed and manufactured according to ASTM D5800 Standard test method for evaporation loss of lubricating oils by the Noack B method.
It is suitable to determine lubricating oil(especially internal combustion engine oil) and the evaporation loss of lubricating base oil at 250ºC.


II. Main technical features
1. Latest technology: adopt B method to instead of A method. There are no wood alloy in process of test to avoid environment pollution and personnel injure.
2.Control method: adopting embedded operating system, high speed microprocessor control, work steadily and reliably.
3.Printing way: with USB printer port,RS232 port, realize the connection and communication between printers and computers.
4. Touching: adopting LCD display, convenient operation by touch screen.
5.Safety: with the inner diagnostic program and many alarms, realize the smart management when instrument's fault.
6. Precision control: built-in high-capacity EPROM,real-time recording the value of temperature and pressure at each minutes.


III. Main technical specifications
1. Temperature control: room temperature to 300ºC
2. Temperature resolution: resolution accuracy  ±0.1ºC
3. Temperature control accuracy: ±0.5ºC
4. Heating unit: environment protection light heating unit
5. Vacuum control: vacuum pump and pressure meter air filter
6. Pressure range: 0~25mm H2O
7. Pressure accuracy: resolution accuracy ±0.05 mm H2O
8. Stability precision: ±0.2 mm H2O
9. Total consumption: less 2200W(heating power 2000W)
10. Environment temperature: ≤30ºC
11. Relative humidity: ≤85%
12. Power supply: AC220V±10%,50Hz
13. Outline dimension:
main uint 550×360×360mm
toolbox: 330×210×80mm
(L*W*H,buit-in 2pcs 2500ml voltage stabilization bottle)


IV.Petroleum & Oil Analyzer Petroleum Testing Instruments
Open Cup Flash Point Tester
Flash & Fire Point Tester for Petroleum Products
Closed Cup Flash Point Tester
Engler Viscometer
Water Content Tester
Rotational Viscometer
Kinematics Viscometer
Distillation Tester
Density Tester
Rust and Corrosion Tester
Sulphur Content Tester
Acid and Alkali Tester
Dropping Point Tester
Demulsibility Characteristics Tester
Ash Content Tester
Aniline Point Tester
Low Temperature Tester(Including solidifying point, cold filter plugging point, pour point, cloud point, and freezing point)
Residue Carbon Tester
Existent Gum Tester
Vapor Pressure Tester
Bomb Calorimeter
OCTANE & CETANE ANALYZER
Lubricating Oils Foaming Characteristics Tester
Petroleum Products Color Tester
Petroleum Wax Oil Content Tester
Automatic Interfacial Tension Tester
Liquid Petroleum Products Hydrocarbon Tester
Lubricating Oil Air Release Value Tester
Petroleum Products and additives Mechanical impurities tester
