Secondary Current Injection Protection Relay Tester Best Price Made in China
Haomai Electric Power Automation Co., Ltd.- After-sales Service：on-Site Training
- Warranty：3 Years
- Output：Max 150V,40A Per Phase
- Frequncy：DC--1200Hz
- Power：6*450va
- AC Accuracy：0.1%
Base Info
- Model NO.：HME-1600
- Resolution：1 Ma
- Binary Input：10-250VDC or Free Contact
- Input Terminal：10
- Binary Output：AC(0.5A, 250V) , DC(0.5A, 60V)
- Output Terminal：8
- Laptop Control：Available
- Testing Software：Differential, Eath Fault, Line Fault etc.
- Transport Package：Standard Export Wooden Package
- Specification：420*360*210
- Trademark：Relaytestar
- Origin：China
- HS Code：903033900
- Production Capacity：100px,Week
Description
6-Phase AC(L-N)
6x0…40A
3-Phase AC(L-N)
3x0…80A
1-Phase AC(LL-LN)
1x0…240A
DC(L-N)
6x0…±20 A
Power
6-Phase AC(L-N)
6x300VA At 40A
3-Phase AC(L-N)
3x450VA At 80A
1-Phase AC(LL-LN)
1x1000VA At 240A
DC(L-N)
6x120VA At 20A
Accuracy
AC: ±1mA(≤0.2A), ≤0.1% (0.2~40A)
DC: ±5mA(0.2~0.5A), ≤0.2% (0.5~20A)
Resolution
1mA
Setting Range 6-Phase AC(L-N) 6x0…150V 3-Phase AC(L-N) 3x0…300V DC(L-N) 6x0…±175V Power 6-Phase AC(L-N) 6x80VA At 150V 3-Phase AC(L-N) 3x100VA At 300V DC(L-N) 6x80VA At 175V Accuracy AC: ±2mV(0.2~2V), ≤0.1% (2~150V) DC: ±10mV (0.5~5V), ≤0.2% (5~175V) Resolution 1mV Auxiliary DCFrequency Range: 0~1200Hz Accuracy:<1mHz(0~65Hz);<10mHz(65~450Hz);<20mHz(450~1200Hz) Resolution: 0.001Hz Phase Range: -360° ~+360° Accuracy: 0.1° Resolution: 0.01° Harmonic Superposition Order: 2~24 Times Distortion: ≤0.5% Power Supply Customized (AC 220V/230V/120V/127V±10%, 1-Phase) Nominal Frequency 50/60 Hz Rated Current 10A At 230V / 12A At 115V Connection Standard AC Socket (IEC 60320) Miscellaneous 18kg(39.68 Lb) Dimensions (W X H X D, Without Handle) 420×360×210mm(16.54x14.17x8.27 In) Connection Port 2 USB2.0 Ports, 1 Ethernet Port High Power 6-phase Protection Relay Test System HME-1600 is the preferred choice for test engineers in cases where excellent transportability is needed and 6-phase current up to 40A are sufficient. Nominal Input Voltage Weight
High Power 6-phase Protection Relay Test System HME-1600 passed the Type Test in China KETOP laboratory accredited under ISO/IEC 17025.
High Power 6-phase Protection Relay Test System HME-1600 is also calibrated in the third party laboratory accredited under ISO/IEC 17025.
HAOMAI ELECTRIC POWER AUTOMATION is established in 1999 and located in Wuhan of China, which is specialized in developing and manufacturing electrical power test and measurement instruments. HAOMAI products are widely used in power grid, petrochemical, metallurgy, railway, coal mine, research institutes and all kinds of large-scale factories or enterprises.mainly focuses on the sales and services of Protection Relay Test System, CT/PT Analyzer, Battery Load Tester, Transformer Testing Equipment, Circuit Breaker Analyzer, Partial Discharge Detector etc. electrical power test and measurement instruments.
HAOMAI follows total quality criteria, and always maintains standardized process and procedures for continuous growth. HAOMAI has been certified by ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007.
HAOMAI builds own RELAYSTAR laboratory and performance test laboratory, and possesses professional production equipment and testing instruments in factory, such as Agilent 34401A 6 1/2 High-precision Meter, FLUKE Multi-meter, EMH Standard Meter, CLOU Standard Power Source, Oscilloscope, Phase Meter, Insulation Test System, High Voltage Dividers, AC High Voltage Generator, Time Calibration Tester, Standard Micro-resistance etc.
HAOMAI is China well-known mark recognized and approved by State Administration for Industry & Commerce of People's Republic of China, and enjoys high reputation in domestic and foreign markets.
HAOMAI now is the key supplier for SGCC(State Grid Corporation of China) and CSG(China Southern Power Grid). Till 2018 HAOMAI products have been sold to 34 different countries.
HAOMAI always sticks to the faith of "cooperation and sharing", takes the "technology and market" as the direction, "creation and innovation" as the soul, listens to clients carefully, and improves the technology, upgrades the products, optimizes the service and tries all to be the global leader in electrical power test and measurement instruments field.
