• Model NO.：P33
• Origin：China
• Production Capacity：5000,Year

Overview Product Description

P33 Piezo Tip/Tilt Platform is a deflection platform with fast response and compact size. It provides high-precision angular motion of the top platform.

Compared with other actuators, the flexible hinge-guided piezoelectric deflection platform provides higher acceleration.

Closed-Loop for High Accuracy
Closed-Loop sensors provide high accuray and feedback position signals to the controller. The sensors are connected in a bridge configuration to eliminate thermal drift and ensure high, stability.
This platform can take Ø25.4mm standard diameter lens, and custom is available for Ø50mm mirror.

Characteristics
- θx or θx, θy tilt
- Tilt range to 12.5mrad
- Sub-ms response time
- High closed-loop positioning accuracy
- High temperature stability
- Custom UHV, etc. is available

Applications
- Image processing and stabilization
- Laser scanning
- Interlaced scanning, jitter
- Optical filter/switch
- Laser micromachining
- Beam deflection
- Adaptive optics, image stabilization
- Interference

Measuring Tilt Angle
Laser collimator is measuring the deflection angle of P33.T2S piezo platform.

 Product Parameters
P33.θXθY axes Technical dataModelsP33.T1SW/B
P33.T1KW/BP33.T2SW/B
P33.T2KW/BP33.T3SW/B
P33.T3KW/BP33.T4SW/B
P33.T4KW/BP33.T5SW/B
P33.T5KW/BP33.T6SW/B
P33.T6KW/BP33.T8SW/B
P33.T8KW/BUnitsActive axisθx,θyθx,θyθx,θyθx,θyθx,θyθx,θyθx,θy Tilt angle(0~120V)1(≈210")
/±0.5(≈±110")2.5(≈520")
/±1.25(≈±260")4(≈820")
/±2(≈±410")5(≈1030")
/±2.5(≈±520")6.8(≈1400")
/±3.4(≈±700")7.5(≈1550")
/±3.75(≈±770")10(≈2060")
/±5(≈±1030")mrad±20%Tilt angle
(0~150V)1.25(≈260")
/±0.625(≈130")3(≈600")
/±1.5(≈±300")5(≈1000")
/±2.5(≈±500")6(≈1200")
/±3(≈±600")8.5(≈1700")
/±4.25(≈±850")9(≈1900")
/±4.5(≈±950")12.5(≈2500")
/±6.25(≈±1250")mrad±20%Sensor typeSGS/-SGS/-SGS/-SGS/-SGS/-SGS/-SGS/- Closed/open loop Resolution0.1(≈0.02")
/0.05(≈0.01")0.05(≈0.01")
0.02(<0.01")0.15(≈0.03")
0.05(≈0.01")0.25(≈0.05")
0.1(≈0.02")0.35(≈0.07")
0.12(≈0.02")0.45(≈0.09")
0.15(≈0.03")0.5(≈0.1")
0.2(≈0.04")μradLinearity-0.1/-0.15/-0.2/-0.25/-0.25/-0.25/-%F.S.Repeatability-0.02/-0.02/-0.02/-0.02/-0.02/-0.02/-%F.S.Unloaded resonant frequency3.83.73.53.43.33.23.1kHz±20%Unloaded step time-1.5/12.5/1.53/25/2.56/3.58/4ms±20%Unloaded operating frequency10% travel11001000800500400300150Hz±20%100% travel90806040302515Capacitance1.8/axis3.6/axis5.2/axis7.2/axis9/axis11/axis14.5/axisμF±20%MaterialSteelSteelSteelSteelSteelSteelSteel Mass150190220240265290340g±5%Platform Length L28374655647391mmNote: Above parameters are measured with the E00/E01 series piezo controller. The maximum driving voltage can be -20V~150V; for high reliability long-term use, the recommended driving voltage is 0~120V.
