• Model NO.：CST-50
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Transport Package：Plywood Exporting Package
• Specification：70kg 0.7CMB
• Trademark：HST
• Origin：Jinan, Shandong, China
• HS Code：9031809090
• Production Capacity：1000 Sets,Month

Basic Info.

Model NO. CST-50 Control Manual Control Weight 0-100Kg Power Source AC220V Transport Package Plywood Exporting Package Specification 70kg 0.7CMB Trademark HST Origin Jinan, Shandong, China HS Code 9031809090 Production Capacity 1000 Sets/Month

Product Description

CST-50  Metal Impact Specimen Profile Projector




1. Application
CTS-50 is a kind of special projector, which amplifies and projects the U or V-shaped profiles of the measured parts to the screen to check their profiles and shapes with high accuracy utilizing the optical projection method. It is widely used to check the U and V-shaped notch of the impact specimen with the features of easy operation, simple structure, direct inspection and high effectiveness.

2.Main Technical Parameters

Diameter of the Screen	200mm
Magnification of the instrument	50X
Objective magnification	2.5X
Working table square shape	110x125mm
Diameter of round worktable	90mm
Diameter of working screen	70mm
Stroke of working table	Longitude: ±10mm,Latitude: ±10mm, Rise and fall: ±12mm
Eye-field diameter	3.8mm
Working distance	22.89mm
Scope of revolving of the worktable	360°
Power supply	220V, 60HZ,150W
Dimension	515×224×603mm
Light source(tungsten halogen lamp)	12V,100W
Weight	18kg

 3. ConfigurationHost----1set
Base adjustment button---4 Pcs
Power line----1Pcs
Halogen tungsten lamp----2Pcs
Flat glass plate ---1Pcs
