Lab Disintegrator for Paper Pulp
Hangzhou Pnshar Technology Co., Ltd.- Type：Vibration Testing Machine
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Transport Package：Seaworthy or Airworthy Package
- Specification：ISO, ASTM, TAPPI
Base Info
- Model NO.：PN-PL28
- Trademark：PNSHAR
- Origin：China
- HS Code：90248000
- Production Capacity：1000sets,Year
Description
Basic Info.
Model NO. PN-PL28 Trademark PNSHAR Origin China HS Code 90248000 Production Capacity 1000sets/YearProduct Description
Description:Lab Disintegrator for paper pulp is vertical type, it dissociates the fibers in the pulp by high rotary speed. It is used for hand sheet forming, the measurement of freeness and material selection etc.
This machine conform to the standards of JIS-P8220, TAPPI-T205, ISO-5263. Simple to operate, reliable, cover sealed, transparent container using ductile materials, visible in mixing process.
| NO. | ITEM | SPECIFICATION |
| 1 | Specimen: | dry pulp 24g, consistency 1.2%, solution 2000ml; |
| 2 | Power supply: | 370W, 380V; |
| 3 | Container volume: | 3.46L; |
| 4 | Pulp volume: | 2000Ml; |
| 5 | Propeller diameter: | 90mm; |
| 6 | Rotary speed: | 3000r/min±5r/min; |
| 7 | Standard rpm: | 50000r (settable) |
| 8 | Outer dimension: | W270×D520×H720mm |
| 9 | Weight: | 50kg |
