Dgbell Constant Temperature and Humidity Test Chamber Environmental Chamber Price

GUANGDONG BELL EXPERIMENT EQUIPMENT CO., LTD.
  • After-sales Service：Support
  • Power Supply：AC380V
  • Certification：CE, ISO
  • Warranty：1 Year
  • Lab Volume：80L-1000L
  • Temperature Range：a:-0~150ºC B:-20~150ºC

Base Info

  • Model NO.：BTH-SERIES
  • Humidity Range：20%Rh-98%Rh
  • Temperature Fluctuation：±0.5ºC
  • Humidity Fluctuation：±2%Rh
  • Heating Rate：Approx 3ºC,Mins,Average Non-Linear ,No Load
  • Cooling Rate：Approx 1ºC, Mins,Average Non-Linear ,No Load
  • Temperature Overshoot：≤±2ºC
  • Internal Material：1.2mm Thick SUS#304 High &Low Temperature Resistan
  • Transport Package：Each Set Protected with Resin Fiber and PP Film, T
  • Specification：Test Space 400x500x400(customizable)
  • Trademark：DGBELL
  • Origin：Guangdong China
  • HS Code：8514109000
  • Production Capacity：100set ,Month

Description

Model

BTH-80

BTH-150

BTH-225

BTH-408

BTH-800

BTH-1000

Test Space

W x H x D (mm)

400x500x400

500x600x500

500x750x600

600x850x800

1000x1000x800

1000x1000x1000

External Dimension

W x H x D (mm)

650x1650x1270

700x1700x1370

700x1750x1420

650x1650x1270

1200x1900x1620

1200x1900x1820

Cooling Method

Air-cooling

Air-cooling

Air-cooling

Air-cooling

Air-cooling

Air-cooling

Temperature Range

A:-0~150ºC   B:-20~150ºC   C:-40~150ºC   D:-70~150ºC

Humidity Range

20%RH-98%RH (details see temperature humidity control diagram).

Temperature Fluctuation

±0.5ºC

Humidity Fluctuation

±2%RH

Temperature Deviation

≤2.0ºC

Humidity Deviation

A)>75%RH:≤+2,-3%RH,B)<75%RH:≤±5%RH.

Temperature Uniformity

≤±2.0ºC

Humidity Uniformity

+2,-3%RH

Heating Rate

Approx 3ºC/mins,average non-linear ,no load

Cooling Rate

Approx 1ºC/ mins,average non-linear ,no load

Temperature Overshoot

≤±2ºC

Internal Material

1.2mm thick SUS#304 high &low temperature resistance stainless steel.

External Material

Adopt flame retardant high strength PU Polyurethane foam insulation material.

Dgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceDgbell Constant Temperature and Humidity Test Chamber Environmental Chamber Price

Established in 2005, Guangdong Bell Experiment Equipment Co., Ltd is specialized in manufacturing a variety of quality inspection instruments, testing equipments and other high-tech products which mainly include: Constant Temperature & Humidity Test Chamber,High & Low Temperature Test Chamber, High & low Temperature Testers with Rapid Temperature Change, Walk-In humidity & temperature test chamber, Cool/Thermal shock test chamber, Salt spray chamber, High temperature aging tester, sand and dust testing machine,tension tester, high and low temperature testing machine , servo computer battery crush tester, mechanical vibration testerBattery washing tester ,battery burning tester and other quality testing instruments. Thanks to several decades of R&D efforts,the company has established itself as a leading provider of testing instruments of the industry, playing a crucial role in the research and development of high-quality and high-value products within the industry.

15+ years experience in test chambers manufacturing, High performance for your projects.

With unmatched quality advantage, a dynamic management team, professional customer services, superb manufacturing techniques and innovative research and development ideas, Guangdong Bell Experiment Equipment Co., Ltd, supported by an international, standard and professional quality policy, is gradually becoming an international brand. Its products are manufactured in consistent with a number of world standards.

Dgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceDgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceDgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceDgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceDgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceDgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceDgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceDgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceDgbell Constant Temperature and Humidity Test Chamber Environmental Chamber PriceComplete QC inspection process,Guarantee high quality of each machine.

1.IQC Incoming Quslity Control2.IPQC InPut Process Quality Control
3.FQC Final Quality Control
4.OQC Outgong Quality Control

Our service:
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual.
Onsite Service:
1.Device installation; 2.Equipment Operation Test Technology training;
3.Equipment Calibration;
4.Daily maintenance and maintenance of equipment Free technical training for visiting factories 24-hour Online contact Free software upgrades
Free information:
1.Product Instruction;
2.Product operation instruction/video;
3.Experiment Test (test application, test report)
Device Problem Handling:
1.Social media 24 hours online communication;
2.Email contact;
3.Video Conferencing;
