IEC Standard China Automatic Transformer Test Bench Transformer Testing System Load Loss No Load Current High Voltage Tester
EP HIPOT ELECTRIC CO., LTD.- After-sales Service:Onsite and Remote Guidance
- Warranty:2 Years Free Warranty Longlife Service
- Type:Universal Testing Machine
- Accuracy Grade:0.05
- Display:LCD
- Control:Computer Control
Base Info
- Model NO.:EPBZ-III
- Weight:1000-2000Kg
- Power Source:AC380V
- Test Capacity:5000kVA
- Control Mode:Manual,PLC
- Test Items:TTR, Dvdf, Resistance, Hipot and Customized
- Keywords:Transformer Testing System
- Test Console Protection:No Load Test Over-Current Protection Power Frequen
- Key Words:Transformer Testing Equipment
- Temperature Rise Test:Regulator and Ohmmeter with Tempera Rise Function
- Test Object:Distribution Transformers Power Transformers
- Protection:No Load Test Over-Current Protection
- Protection1:Power Frequency Over-Current Protection.
- Protection2:Zero Start Interlock with Auto Return of Regulator
- Protection3:Separate Ground Fault Safety Circuit.
- Protection4:External Interlock Provision.
- Protection5:Emergency Stop Mushroom Button.
- Protection6:Alarm Sound & Light During Test.
- Transport Package:Plywood Cases
- Specification:10+m3
- Trademark:EP Hipot Electric
- Origin:Wuhan, China
- HS Code:8504349000
- Production Capacity:100,Year
Description
Basic Info.
Model NO. EPBZ-III Weight 1000-2000Kg Power Source AC380V Test Capacity 5000kVA Control Mode Manual/PLC Test Items TTR, Dvdf, Resistance, Hipot and Customized Keywords Transformer Testing System Test Console Protection No Load Test Over-Current Protection Power Frequen Key Words Transformer Testing Equipment Temperature Rise Test Regulator and Ohmmeter with Tempera Rise Function Test Object Distribution Transformers Power Transformers Protection No Load Test Over-Current Protection Protection1 Power Frequency Over-Current Protection. Protection2 Zero Start Interlock with Auto Return of Regulator Protection3 Separate Ground Fault Safety Circuit. Protection4 External Interlock Provision. Protection5 Emergency Stop Mushroom Button. Protection6 Alarm Sound & Light During Test. Transport Package Plywood Cases Specification 10+m3 Trademark EP Hipot Electric Origin Wuhan, China HS Code 8504349000 Production Capacity 100/YearProduct Description
IEC Standard China Automatic Transformer Test Bench Transformer Testing System Load Loss No Load Current High Voltage TesterGeneral Information:
EPBZ series Transformer Test Bench is applied for ex-work and maintenance detecting on various transformers. It's widely used in the fields of power supply and distribution, power transformer manufacturer, transformer maintenance center, industry and mining enterprises.
Features
- Applied for different voltage degree transformers, reactors and HV switchgears.
- Fully PLC controlling and measurement, integrated primary wire connection circuit displaying, measuring, control tracing, analysis processing, report storing, printing and protecting into the testing system.
- All the test data calculation was operated by IPC, the test results and measuring data are displayed in screen directly which highly improved the precision and efficiency.
- The test system could be customized to bench type, microcomputer type or any at user's option to be suitable for your test site.
- All test results are corrected according to the requirement of IEC60076 or ANSI C57.
Test Items:
Routine tests:
- Transformer oil testing (including acidity, dewpoint, flashpoint, breakdown, capacitance &tan delta, dissolved gas analysis)
- Transformer insulation resistance testing
- Transformer winding resistance testing
- Transformer turns ratio testing
- Transformer load/no-load current & loss testing
- Transformer capacitance & tan delta testing
- Transformer short circuit impedance & load loss testing
- Transformer power frequency withstand voltage testing
- Transformer induced AC withstand voltage testing (including 110kV transformer partial discharge testing)
- Impulse voltage testing (including full wave, chopping wave testing)
Type tests:
- Temperature rising testing
Special tests:
- Zero-sequence impedance testing
- No load current harmonic testing
Function features:
- 3 phase 4 wires power supply controlling.
- Regulator supply controlling.
- Regulator voltage controlling.
- CT/PT shifting controlling.
- Test voltage/current monitoring for each test item.
- Function switching for each test item.
- Inductive motor start, stop, voltage increase/decrease, auto timing.
- Panel pushbuttons, PC mouse two control modes.
- PLC software operating and save test results automatically.
- No load test over-current protection
- Power frequency over-current protection.
- Zero start interlock with auto return of regulator to zero position.
- Separate ground fault safety circuit.
- External interlock provision.
- Emergency stop mushroom button.
- 3 phase 4 wires main power supply.
- Alarm sound & light during test.
1 | Transformer Test Bench | 7 | DC winding resistance tester |
2 | Inductive regulator | 8 | Transformer turns ratio tester |
3 | Motor Generator sets (DVDF) | 9 | Insulation resistance meter |
4 | Intermediate transformer (voltage boosting transformer if LV is over 400V) | 10 | Power frequency withstand voltage test set |
5 | Sampling cabinet (HV/LV CT/PT cabinet, primary circuits cabinet) | 11 | Temperature Tester |
6 | Power analyzer | 12 | Partial discharge system (PDF detector, coupling capacitor etc.) |
More details on EPBZ series Transoformer Test System please contact EP Hipot Electric, we have professional tech team to design correctly designed products and systems.
