Schenck Field Balancing Machine - Portable Smart Balancer

Schenck Shanghai Machinery Corp. Ltd.
  • Type：Vibration Testing Machine
  • Load Way：Mechanical Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Manual Control
  • Weight：0-100Kg

Base Info

  • Model NO.：Smart Balancer
  • Power Source：AC220V
  • Size：Portable
  • Transport Package：pallet
  • Specification：CE
  • Trademark：schenck
  • Origin：Shanghai
  • HS Code：90031900
  • Production Capacity：20

Description

SmartBalancerNo. of measurement channels2No. of measurement pointsmax. 4Balancing speed120 - 60.000 min-1PC connectionRS-232 serial interface with 9.600 - 115.200 baud data transfer ratePower supply and charging unit110 V - 240 V / 50 Hz to 60 HzPower supplyRe-chargeable Lithium ion battery packBattery operating time8 hoursWorking temperature range-10°C bis +50°CMeasurement functionsField balancing Measurement of overall vibration Frequency analysis Run-up and run-down curves Vibration versus time Phase
measurementDisplayTFT-LCD, backlit Color depth: 18 bit (262144 colors), Resolution: VGA (640 x 480 pixel) w/ 140 ppi Pixel area: 116 x 87 mmKeyboard1 navigation pad and 7 keys; Keyboard illumination controlled by ambient lightWeight1,15 kg (Measuring instrument)Dimensions186 x 162 x 52 mm (Measuring instrument)
