Ceyear 4051 Series Signal/Spectrum Analyzer (3Hz~4GHz/9GHz/13.2GHz/18GHz/26.5GHz/40GHz/45GHz/50GHz/67GHz) Equivalent to Keysight R&S
Ceyear Technologies Co., Ltd.- After-sales Service:Local Distributor
- Function:Signal,Spectrum Analysis
- Display:10.1 Inches LCD Touchscreen
- Usage:RF,Microwave,Mmw
- Type:Benchtop Instrument
- Environment:0-50ºC
Base Info
- Model NO.:4051
- Warranty:3 Year Warranty
- Power Source:AC 100-240V
- Weight:〉10Kg
- Installation:Direct Connected
- Customized:Non-Customized
- Transport Package:Aluminum Transportation Case
- Specification:W*H*D= 498mm*192mm*532mm
- Trademark:Ceyear
- Origin:China
- HS Code:9030849000
- Production Capacity:500 Pieces , Year
Description
4051A/4051B/4051C/4051D/4051E/4051F/4051G/4051HFrequency range 3Hz~4GHz/9GHz/13.2GHz/18GHz/26.5GHz/40GHz/45GHz/50GHz 10MHz
Precise frequency reference Frequency accuracy: ± (last calibration date × aging rate + temperature stability + calibration accuracy)
Aging rate: ± 1´10-7/year
Temperature stability: ± 1.5´10-8 (20°C ~ 30°C) ± 5´10-8 (0°C ~ 55°C) (±1.5´10-8)
Calibration accuracy: ± 4 ´10-8 Frequency readout accuracy ± (frequency readout × frequency reference accuracy+0.1% frequency band+5% resolution bandwidth+2Hz+0.5 horizontal resolution*)
*: horizontal resolution = span/ (sweep points number - 1) Frequency counting accuracy ± (frequency readout × frequency reference accuracy+0.1Hz) Span Range:0Hz (zero span), 10Hz~the highest frequency of the model
Accuracy: ± (0.1%× span+span/ (sweep points number-1)) Sweep time range span≥10Hz: 1ms~4000s
span=0Hz: 1us~6000s Resolution bandwidth Range: 1Hz~3MHz (1, 2, 3, 5 stepping) 4, 5, 6, 8, 10MHz
Conversion uncertainty: £ ± 0.3dB Video bandwidth 1Hz~3MHz (1, 2, 3, 5 stepping) 4, 5, 6, 8, 10MHz (rated value) Signal analyzing bandwidth 10Hz~10MHz (standard), 40MHz (option), 200MHz (option) Memory depth 500MSamples Trigger mode Free, power source, video, external level (front panel), external level (back panel), burst RF, timer Wave-detection mode Normal, positive peak, negative peak, sampling,video average power average, voltage average SSB phase noise
(1GHz carrier,20°C ~ 30°C) Frequency offset Feature Typical 100Hz -96dBc/Hz -105dBc/Hz 1kHz -115dBc/Hz -118dBc/Hz 10kHz -125dBc/Hz -129dBc/Hz 100kHz -125dBc/Hz -129dBc/Hz Residual FM (central frequency 1 GHz, resolution bandwidth 10Hz, video bandwidth 10Hz) ≤(0.25 Hz x N) p-p,the rated value within 20 ms
N is the number of frequency multiple times of LO Displayed average noise level (the input end is connected to match load, sampling or average wave detection, the average type is logarithm, 0dBinput attenuation, RF gain takes the DANL as the priority, 20°C ~ 30°C) Frequency range Feature Typical 10MHz~1GHz -153dBm/Hz -156dBm/Hz 1GHz~2GHz -151dBm/Hz -154dBm/Hz 2GHz~3GHz -150dBm/Hz -153dBm/Hz 3GHz~3.6GHz -148dBm/Hz -151dBm/Hz 3.6GHz~4GHz -145dBm/Hz -148dBm/Hz 4GHz~4.4GHz -148dBm/Hz -152dBm/Hz 4.4GHz~9GHz -150dBm/Hz -152dBm/Hz 9GHz~18GHz -148dBm/Hz -151dBm/Hz 18GHz~26.5GHz -143dBm/Hz -146dBm/Hz 26.5GHz~40GHz -138dBm/Hz -144dBm/Hz 40GHz~50GHz -133dBm/Hz -141dBm/Hz Frequency range With preamplifier (on) With preamplifier (on,typical) 10MHz~1GHz -162dBm/Hz -164dBm/Hz 1GHz~2GHz -162dBm/Hz -165dBm/Hz 2GHz~3GHz -160dBm/Hz -164dBm/Hz 3GHz~3.6GHz -156dBm/Hz -163dBm/Hz 3.6GHz~4GHz -155dBm/Hz -162dBm/Hz 4GHz~4.4GHz -155dBm/Hz -164dBm/Hz 4.4GHz~9GHz -155dBm/Hz -164dBm/Hz 9GHz~18GHz -154dBm/Hz -160dBm/Hz 18GHz~26.5GHz -154dBm/Hz -157dBm/Hz 26.5GHz~40GHz -150dBm/Hz -152dBm/Hz 40GHz~50GHz -145dBm/Hz -150dBm/Hz Frequency response & absolute amplitude accuracy (10dB attenuation,
20°C ~ 30°C) Frequency range Feature Typical feature 3Hz~20MHz <±0.7dB <±0.5dB 20MHz~2GHz <±0.5dB <±0.4dB 2GHz~3.6GHz <±0.7dB <±0.5dB 3.6GHz~4GHz <±1.0dB <±0.8dB 4GHz~9GHz <±1.5dB <±0.9dB 9GHz~18GHz <±2.0dB <±1.0dB 18GHz~26.5GHz <±2.5dB <±1.2dB 26.5GHz~40GHz <±3.0dB <±1.8dB 40GHz~50GHz <±3.0dB <±2.0dB Frequency range Preamplifier on/off Preamplifier on/off (typical) 3Hz~20MHz <±1.2dB/±1.5dB <±0.6dB/±0.6dB 20MHz~2GHz <±1.0dB/±1.5dB <±0.6dB/±0.8dB 2GHz~3.6GHz <±1.2dB/±1.5dB <±0.6dB/±0.9dB 3.6GHz~4GHz <±1.5dB/±1.8dB <±1.0dB/±1.2dB 4GHz~9GHz <±2.0dB/±2.5dB <±1.3dB/±1.5dB 9GHz~18GHz <±2.5dB/±3.0dB <±1.5dB/±1.6dB 18GHz~26.5GHz <±3.0dB/±3.5dB <±1.6dB/±1.8dB 26.5GHz~40GHz <±3.5dB/±4.0dB <±2.2dB/±2.3dB 40GHz~50GHz <±3.5dB/±4.0dB <±2.4dB/±2.6dB Absolute amplitude accuracy (10 dB attenuation, 20°C ~ 30°C, 1 Hz ≤resolution bandwidth≤ 1 MHz, input signal -10 ~ -50 dBm):
±0.24dB 500MHz
± (0.24dB+frequency response) all frequency 1dB gain compression (mixer level, dual-tone test, resolution bandwidth is 5kHz, 3MHz frequency interval, 20°C ~ 30°C) Frequency range Feature 20MHz~40MHz -3dBm 40MHz~200MHz +1dBm 200MHz~4GHz +3dBm 4GHz~9GHz -1dBm 9GHz~50GHz +1dBm TOI distortion (
input mixer 2 -10dBm signal test, frequency interval is 50kHz,20ºC~30ºC) Frequency range Feature Typical feature 10MHz~200MHz +13dBm +15dBm 200MHz~4GHz +13dBm +16dBm 4GHz~9GHz +11dBm +15dBm 9GHz~18GHz +13dBm +15dBm 18GHz~50GHz +13dBm +17dBm Residual response
(the input end is connected to match load, 0dB attenuation) -100dBm 200kHz~9GHz
-100dBm (rated value) other frequency Dimensions W×H×D= 498mm×192mm×532mm (including handle, foot-pad, bottom feet)
W×H×D= 426mm×177mm×460mm (excluding handle, foot-pad, bottom feet) Weight About 25kg (different configuration cause different weight) Power supply AC 220/240V: 50/60Hz Power consumption Standby: less than 20W; operating: less than 400W Temperature range Operating temperature: 0°C ~ +50°C; storage temperature: -40°C ~ +70°C Input connector AV4051A/B/C/D: type N (female), impedance: 50Ω
AV4051E: 3.5mm (male), impedance: 50Ω
AV4051F/AV4051G/AV4051H: 2.4mm (male), impedance: 50Ω Notes:
1. Rated values refer to the estimated performance, or the performance which is useful for the product beyond the warrant range.
2. Typical value refers to other performance information beyond the product guarantee range; when the performance is over the technical index, 80% of the samples will present 95% confidence within 20°C ~ 30°C temperature range; typical performance excludes test uncertainty
FAQ
1. What is the relationship between China Electronics Technology Instruments Co., Ltd and Ceyear Technologies Co., Ltd?
China Electronics Technology Instruments Co., Ltd is the former name of Ceyear Technologies Co., Ltd before Year 2021, but the brand of both are all Ceyear. SInce the beginning of 2021, as Ceyear is to be a listed company, the name was transformed from China Electronics Technology Instruments Co., Ltd to Ceyear Technologies Co., Ltd. Therefore, in previous product introductions and company catalog, sometimes you can still find the name of China Electronics Technology Instruments Co., Ltd
2. Is Ceyear a manufacturer or a trading company?
Ceyear is a manufacturer first, with R&D team (around 1500 engineer), production line (around 500 people), and domestic and overseas slaes team.
Thus Ceyear is a company integrating R&D, production and sales.
3. What products do you have?
T&M instruments, optical communication tools, microwave component, test systems, and other customized products.
4. How can I get local sevice?
Ceyear has worked with local distributors in different countries for many years, and could provide local after-sale services with the help of those local partners. If you already have some products of Ceyear(previously EI brand included) and looking for services, you can directly contact us through Made-in-China platform.
Precise frequency reference
Aging rate: ± 1´10-7/year
Temperature stability: ± 1.5´10-8 (20°C ~ 30°C) ± 5´10-8 (0°C ~ 55°C) (±1.5´10-8)
Calibration accuracy: ± 4 ´10-8
*: horizontal resolution = span/ (sweep points number - 1)
Accuracy: ± (0.1%× span+span/ (sweep points number-1))
span=0Hz: 1us~6000s
Conversion uncertainty: £ ± 0.3dB
(1GHz carrier,20°C ~ 30°C)
N is the number of frequency multiple times of LO
20°C ~ 30°C)
±0.24dB 500MHz
± (0.24dB+frequency response) all frequency
input mixer 2 -10dBm signal test, frequency interval is 50kHz,20ºC~30ºC)
(the input end is connected to match load, 0dB attenuation)
-100dBm (rated value) other frequency
W×H×D= 426mm×177mm×460mm (excluding handle, foot-pad, bottom feet)
AV4051E: 3.5mm (male), impedance: 50Ω
AV4051F/AV4051G/AV4051H: 2.4mm (male), impedance: 50Ω
1. Rated values refer to the estimated performance, or the performance which is useful for the product beyond the warrant range.
2. Typical value refers to other performance information beyond the product guarantee range; when the performance is over the technical index, 80% of the samples will present 95% confidence within 20°C ~ 30°C temperature range; typical performance excludes test uncertainty
