Yogurt Cups Opening Force Tester China Factory Price
Pubtester Instruments Co., Ltd.- After-sales Service：on Line
- Warranty：12 Months
- Mass Scope of Workpiece：1000kg
- Type：Tensile Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.1
Base Info
- Model NO.：TST-02H
- Load Way：Electronic Load
- Display：Digital
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Speed of Crossbeam：0.05~3000 mm,Min (Adjustable)
- Accuracy of Speed：1%
- Maximum Stroke：1000mm
- Specimen Width：30mm(Standard); 50mm(Optional)
- Clamping Way：Manual(Standard); Pneumatic(Optional)
- Transport Package：Veneer Case
- Trademark：Pubtester
- Origin：Jinan, Shandong
- Production Capacity：10 Sets,Quarter
Description
Extended Application**Tensile Strength & Deformation Rate Puncture Resistance Test of Artificial Skin Puncture Test of Films Puncture Resistance of Infusion Bag Closures Puncture/Pullout Test of Flexible Rubber Closures Tensile Stress at Break Opening Resistance Test of Combined Covers Tear Test of ZD - Type Caps Tearing Resistance Test of Oral Liquid Caps Puncture/Pullout Test of Oral Liquid Caps Heat Seal Strength 90 Degree Pullout Force Test of Infusion Bag Closure Pullout Test of Infusion Bag Closure 23 Degree Pullout Test of Bottle Caps Puncture/Pullout Test of Flexible Rubber Closures Tearing Strength 90 Degree Peel Test of Adhesive Tapes Tear Resistance Test of Adhesive Binding Books 90 Degree Peel Test of Water-soluble Plasters Tearing Resistance Test of Adhesives Shearing Strength Adhesive Strength Test (soft) Adhesive Strength Test (Hard) Peel Test of Flexible Tube Caps Removal Force of Pipes and Pipe Joints 180 degree Peel Test Pullout Test of Cosmetic Brush Hair Pullout Test of Tooth Brush Hair Tensile Strength of Ropes at Break Opening Force Test of Jelly Cups and Yogurt Cups 90 Degree Peel Test Peel Test of Cup Films Pullout Test of Rubber Closure 45 Degree Peel Test of Bottle Membranes Tensile Strength of Sealing Bags Stress at elongation Peel Test of Magnetic Cards 90 Degree Peel Test of Magnetic Cards Tearing Resistance of Heat-sealable Films Separating Force Test of Protective Films Compression test Separating Force of Release Paper Tear Test Using Trouser Method Unwrapping Force of Adhesive Tapes Compression Resistance Test of Plastic Bottles Connection force test 20 Degree Peel Test 135 Degree Peel Test of Plugs Peeling Grips of Floating Rollers Eccentric Grips User defined test Wide Sample Grips Japanese Sample Grips British Sample Grips
Note: *Additional accessories or customized sample grips may need to be purchased separately to complete the tests that cannot be completed with standard sample grips.
** Customized grips are needed for extended applications
Standards
ISO 37, ASTM E4, ASTM D882, ASTM D1938, ASTM D3330, ASTM F88, ASTM F904, GB 8808, GB/T 1040.1-2006, GB/T 1040.2-2006, GB/T 1040.3-2006, GB/T 1040.4-2006, GB/T 1040.5-2008, GB/T 4850-2002, GB/T 12914-2008, GB/T 17200, GB/T 16578.1-2008, GB/T 7122, GB/T 2790, GB/T 2791, GB/T 2792, GB/T 17590, JIS P8113, QB/T 2358, QB/T 1130, YY/T0148
Configuration
Standard configuration: Instrument, Computer, Universal Grips, Professional Software, Communication Cable, HP Printer, Portable Control Box
Optional configuration: Test plate (50×125mm, 40×180mm, 50×200mm and others need to be customized), sample cutter (10#, 15#, 20#, 25#, 25.4#, others need to be customized), standard pressure roller, Pneumatic grip, extensometer, calibration weight, GMP software, Adhesive tape unwinding fixture, needle puncture fixture, ampoule bottle breaking fixture, needle and needle base connection force fixture, needle cap pull-out force test fixture, piston sliding performance test fixture, body tightness test fixture, rubber plug puncture force test fixture, medical catheter link firmness test fixture, food and medicine daily chemical packaging test fixture, etc.
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
