• Model NO.：KU-1000S
• Temperature Range：-70oc~+150oc
• Humidity Constancy：+,-0.5%
• Cooling Rate：0.7oc~1.0oc,Min
• Pressure Range：Normal Pressure~1kp
• Pressurized Parts：High Quality Steel Plate(Rust Proof&Plastic Spray
• Insulation Material：High Quality Glass Wool
• Pump：Rotary Vane Type Vacuum Pump
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：100-500kg

Specifications ModelKU-504LKU-1000LKU-504SKU-1000SInner Size (D*W*H)mm800*700*9001000*1000*1000800*700*9001000*1000*1000Capacity ( KW )11151618Chamber Volume ( L )50410005041000PerformanceTemp range-40 ºC~ +150 ºC-70 ºC~ +150 ºCTemp constancy±0.5 %Temp deviation≥ 100 ºC, ±3.0 ºC( at constant pressure with empty load )< 100 ºC, ±2.0 ºC( at constant pressure with empty load )Cooling rate0.7 ºC~ 1.0 ºC /min ( Overall average )Pressure rangeConstant pressure  ~ 1kPaPressure constancyWhen  ≥ 40kPa, ±2kPa,     4kPa ~ 40pKa  ±0.5kPa,   when ≤ 4kPa, ±0.1kPaDepressurization rateConstant pressure ~ 1kPa≤30mins ( Normal temp )Pressure recovery rate10kPa/Min(adjustable )MaterialExterior materialCold-rolled steel sheet(Rust proof&Plastic Spray treated)/Stainless Steel plateInterior materialStainless steel ( SUS304 )Pressurized partsHigh quality steel plate(Rustproof & Plastic spray treated)  Insulation materialHigh-quality glass woolCooling SystemCompressorSemi-Hermetic CompressorCooling ModeWater-cooledTemp regulating methodBalanced Temperature & Humidity Control System  (BTHC )PumpRotary vane type vacuum pumpHeaterIron-chrome wire heaterSight windowCircular viewing glass incorporating heat generatorTemp SensorPt-100ControllerTouch Screen Controller  Safety DevicesOverpressure, overheat, and over current protection for compressor, over temp. protection, overload protection for the blower,   Hydraulic and Water lack Protection, leakage protection, phase-lack protection, Pump failure alarmStandard AccessorySight window, Cable Port( 1 located on the left side), Baffle, Baffle frame*2  PowerAC380V/50Hz, 3Phase 5 wires+ Ground Wire. Note:
1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available

Packaging

Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.

After-sale service

If you face any problems in the future during the testing process,  we promise we will give you a reply within 48 hours and a solution provided within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by the customer.
