• Model NO.：Ceyear 1465-V
• Warranty：3 Year Warranty
• Power Source：AC 100-240V
• Weight：〉10Kg
• Installation：Direct Connected
• Customized：Non-Customized
• Transport Package：Aluminum Alloy Box
• Specification：W*H*D=482mm*152mm*582mm
• Trademark：Ceyear
• Origin：China
• HS Code：8543209090
• Production Capacity：500 Pieces , Year

Frequency propertiesFrequency range1465C-V:100kHz~10GHz
1465D-V:100kHz~20GHz
1465F-V:100kHz~40GHz
(Max. frequency of 44GHz)
1465H-V:100kHz~50GHz
1465L-V:100kHz~67GHzFrequencyN(Internal YO harmonic order)100kHz≤f≤250MHz1/8250MHz1/16500MHz1/81GHz1/42GHz1/23.2GHz110GHz220GHz328.5GHz550GHz10Frequency
resolution0.001HzFrequency
switching time<20msTime-base aging rate(Typical value2)5×10 -10 /day(after 30-day continuous power-on)Reference outputFrequency10MHzPower>+4dBm,to 50ΩReference inputFrequency1-50MHz,1Hz stepPower-5dBm-+10dBm,50Ω impedanceSweep propertiesSweep modeStep sweep, List sweep, Analog sweep, Power sweepAnalog sweep
(option H03)Max. sweep speed100kHz≤f≤500MHz25MHz/ms500MHz50MHz/ms1GHz100MHz/ms2GHz200MHz/ms3.2GHz400MHz/msSweep
accuracy0.05 % Sweep width(for 100m, within the maximum width of 100ms as specified)Power propertiesMin. powerModelStandard
packageOption H01A/B1465C/D/F-V-20dBm-110dBm(-135dBm configurable)1465H/L-V-20dBm-90dBm(-110dBm configurable)Max. power
(25±10°C)Frequency rangeStandard
packageH01A/B
programmable step
attenuator
optionH05
high
power
output optionOptions H01A/B+H051465C/D-V    100kHz≤f≤20GHz15dBm15dBm203dBm203dBm1465F-V    100kHz≤f≤9GHz10dBm10dBm18dBm18dBm9GHz<f≤30GHz10dBm10dBm15dBm15dBm30GHz<f≤40GHz10dBm10dBm12dBm12dBm1465H/L-V    100kHz≤f≤15GHz5dBm5dBm15dBm15dBm15GHz<f≤30GHz5dBm5dBm12dBm12dBm30GHz<f≤60GHz5dBm4dBm8dBm6dBm60GHz<f≤67GHz4dBm3dBm6dBm4dBmPower accuracy
(25±10°C)Standard           Power Frequency(dBm)>10~20>-10~10-20~-10100kHz≤f≤2GHz±0.8dB±0.6dB±1.5dB2GHz<f≤20GHz±0.8dB±0.8dB±1.5dB20GHz<f≤40GHz±1.0dB±0.9dB±1.8dB40GHz<f≤50GHz---±1.3dB±1.8dB50GHz<f≤67GHz---±1.5dB±2.0dBH01A/B programmable step attenuator option            Power Frequency(dBm)>10~20>-10~10>-70~-10-90~-70100kHz≤f≤2GHz±0.8dB±0.6dB±0.7dB±1.5dB2GHz<f≤20GHz±0.8dB±0.8dB±0.9dB±1.8dB 20GHz<f≤40Ghz±1.0dB±0.9dB±1.0dB±2.0dB 40GHz<f≤50GHz---±1.3dB±1.5dB±2.5dB 50GHz<f≤67GHz---±1.5dB±1.8dB±3.0dBPower resolution0.01dBPower
temperature
Stability0.02dB/ºC(typical value)Output Impedance50Ω(Rating4)VSWR
(Internal fixed
amplitude)
(typical Value)100kHz≤f≤20GHz<1.620GHz<1.840GHz<2.0Max. reverse power0.5W(0V DC)(rating)Spectrum purity5Harmonic
(at +10dBm or Max. specified output power, whichever is lower)FrequencyStandard package100kHz≤f≤10MHz<-25dBc10MHz<-30dBc2GHz
(1465B)<-30dBc2GHz<-55dBc20GHz<-45dBc(typical value)Sub-harmonic
(at +10dBm or Max. specified output power, whichever is lower)100kHz≤f≤10GHzNone10GHz<-60dBc20GHz<-45dBcNon-harmonic
(at 0dBm, beyond 3kHz offset)FrequencyStandard packageOption H04100kHz≤f≤250MHz<-58dBc<-58dBc250MHz<f≤3.2GHz<-74dBc<-80dBc3.2GHz<f≤10Ghz<-62dBc<-70dBc10GHz<f≤20GHz<-56dBc<-64dBc20GHz<f≤28.5GHz<-52dBc<-52dBc28.5GHz<f≤40GHz<-45dBc<-45dBc40GHz<f≤60GHz<-42dBc<-42dBcSingle side band
phase noise
(dBc/Hz, +10dBm or Max. output power, whichever is smaller)Frequency1Hz10Hz100Hz1kHz10kHz100kHz100kHz≤f≤250MHz-------104-121-128-130250MHz<f≤500MHz-------108-126-132-1360.5 GHz<f≤1GHz-------101-121-130-1301GHz<f≤2GHz-------96-115-124-1242GHz<f≤3.2GHz-------92-111-120-1203.2GHz<f≤10GHz-------81-101-110-11010GHz<f≤20GHz-------75-95-104-10420GHz<f≤28.5GHz-------69-89-98-9828.5GHz<f≤50GHz-------64-84-92-9250GHz<f≤67GHz-------57-77-86-86H04 ultra low phase noise option100kHz≤f≤250MHz6-64-92-105-123-138-141250MHz<f≤500MHz-67-93-111-126-138-1420.5GHz<f≤1GHz-62-91-105-123-138-1381GHz<f≤2GHz-57-86-100-117-133-1332GHz<f≤3.2GHz-52-81-96-113-128-1283.2GHz<f≤10GHz-43-72-85-105-120-12010GHz<f≤20GHz-37-66-79-98-114-11420GHz<f≤28.5GHz-31-60-73-91-108-10828.5GHz<f≤50GHz-26-54-68-85-102-102 50GHz<f≤67GHz-20-48-62-79-96-96Modulation propertiesFrequency
Modulation
(option H02A)Maximum deviation:N×16MHz (N: YO  harmonic number)
Accuracy (at 1kHz, N×20kHz≤deviation<N×800kHz):
< ± (3.5%×set frequency offset + 20Hz)
Modulation rate(3dB bandwidth, N×500kHz frequency offset): DC-10MHz
Distortion(at 1kHz, N×20kHz≤deviations<N×800kHz): <1%Phase
Modulation
(option H02A)Maximum deviation:
Normal mode: N×16rad (N: YO harmonic number)
Broadband mode: N×1.6rad (N is YO harmonic number)
Accuracy(at 1kHz, N×0.2rad≤deviations
<± (5% of deviation + 0.01 rad)
Modulation rate (3dB bandwidth,Broadband mode): DC~10MHz (typical value)
Distortion (at 1kHz, N×0.8rad≤deviationsAmplitude
modulation
(option H02A)Max. depth:>90%
Modulation rate (3 dB bandwidth, 30% modulation depth): DC~100kHz
Accuracy (1kHz modulation rate, 30% modulation depth): ±(6% of setting + 1%)
Distortion (1kHz modulation rate, linear mode, THD, 30% modulation depth): <1.5%Pulse Modulation
(option H02B) 500MHz-3.2GHz>3.2GHzSwitch ratio>80dB>80dBRise and fall time<20ns<20nsMin. pulse width with ALC on1μs1μsMin. pulse width with ALC off0.1μs0.1μsNarrow
pulse Modulation
(option H02C) 50MHz-3.2GHz>3.2GHzSwitch ratio>80dB>80dBRise and fall time<15ns<10nsMin. pulse width with ALC on1μs1μsMin. pulse width with ALC off30ns20nsInternal modulation signal generator
(option H02A/B/C)There are 3 independent signals respectively for frequency/phase modulation, amplitude modulation and low frequency output signals.
Waveform: sine, square, triangle, Sawtooth, noise, double sine, sweep sine.
Frequency range: DC~10MHz for sine, double sine, sweep sine; 0.1Hz~100kHz for square, triangle, sawtooth.
Frequency resolution: 0.1Hz
Low frequency output: Amplitude: 0-5Vpeak(rating), to 50Ω load.
Pulse modulation signal: pulse width: 20ns-(42s-10ns);
pulse period: 100ns-42s;
resolution: 10ns.Vector modulation accuracy(after calibration, 25ºC±10ºC)
(4Msps, root-Nyquist, α=0.3, QPSK, 0dBm)1465C/D/F-V50MHz-40GHz(or max. frequency)EVM(RMS%)<1.4%1465H/L-V50MHz-40GHzEVM(RMS%)<1.4%40GHz-67GHz(or max. frequency)EVM(RMS%)<2.5%Internal modulation bandwidth(Carrier 900MHz, 1.8GHz, 2.4GHz, 6GHz, 18GHz, 35GHz, 50GHz)
Standard package:
120MHz(Multi-tone, Tone quantity: 51, Frequency space: 2.4MHz,±3dB bandwidth);
H3 large modulation bandwidth option:
200MHz(Multi-tone, Tone quantity: 51, Frequency space: 4MHz, ±3dB bandwidth).External modulation Bandwidth(Carrier 900MHz,1.8GHz,2.4GHz,6GHz,18GHz,35GHz,50GHz)
200MHz(ALC OFF,  input 100mVrms sine to channel I, ±4dB bandwidth)External wide modulation Bandwidth
(option H33)(6GHz,18GHz,35GHz,50GHz)
2GHz(ALC OFF,  input 100mVrms sine to channel I, ±4dB bandwidth)Internal baseband signal generatorChannel quantities:2(I and Q)
Max. symbol rate:
    standard package: 60Msps(Max. 4bit/symbol)
option H31: 125Msps(Max. 4bit/symbol)
Baseband waveform internal memory:
    standard package: 1GSa
option H32: 2GSa
Modulation format:
    PSK: BPSK, QPSK, OQPSK, π/4 DQPSK, D8PSK, 16PSK;
    QAM: 4, 16, 32, 64, 128, 256, 512, 1024;
    FSK: 2, 4, 8, 16;
    ASK;MSK; Arbitrary wave modulation.
Dual-tone mode max. frequency offset: 200MHz
EVM: <1.0%(typical value)(RMS%, Symbol rate 4Msps, root-Nyquist, α=0.3, QPSK)General propertiesRF output port1465C-V: N(female), impedance 50Ω.
1465D-V: 3.5mm(male), N(female)(option H91), impedance 50Ω.
1465F-V: 2.4mm(male), impedance 50Ω.Max. Physical DimensionW×H×D: 517mm×192mm×550mmWeight<28 kg(as per model and option configuration)Power Supply100-120VAC, 50-60Hz; or 200-240VAC, 50~60Hz(self-adaptive)Power Consumption<400WTemperature RangeWorking temperature:0ºC~+50ºC;Storage temperature:-40ºC~+70ºCNotes:
1. When 1465-V series signal generator is under environment temperature for 2 hours, attenuator is automatically coupling(or ALC power>-5dBm)after 30 minutes warm-up time. The generator meets every parameter performance within given working temperature.
2. Typical value is a supplementary characteristic just for user's reference. These specifications are not guaranteed.
3. 1465B-V is +16dBm.
4. Rating value is an expected performance, or used to describe the product performance which is useful but not included in product performance warranty.
5. Spectral purity parameter is tested in a certain frequency without any modulation.
6. The single sideband phase noise of 100kHz≤f≤250MHz is tested a output power of +15dBm. The working frequency range of option H06 is greater than 100MHz,so there's no tested specification under 100MHz.
