• Model NO.：KMH-36L
• Temp. Constancy：+,-0.5oc
• Humidity Constancy：+,-2.5%R.H.
• Humidity Uniformity：+,-5.0r.H.
• Heat up Time：-20 Oc~+100 Oc Within 35mins
• Pull Down Time：+20 Oc~-20 Oc Within 45mins
• Equipment Power：18.5kw
• Interior Size：W100 X H100 X D100cm
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets Per Yesr

ModelKMH-36L36L chamber volumeTemp. range -40°C ~150°C Display resolution0.1°CTemperature stabilityHigh±0.5°C, low ±1.0°CTemperature uniformity ±2.0°CHeat uptime -40°C ~+100°C, within 45 minPull downtime +20°C ~-40°C, within 60 minHumidity range20~98%R.H,(standard),   '10~98%R.H,(with humidifier)Humidity constancy±2.5%R.HHumidity uniformity±3.0%R.HInterior Dimension(mm)300W x 400H x 300D Exterior Dimension(mm)880W x 1726H x 1395DInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolTotal power  4KW(heater 2KW included)Max current8AWater Consumption0.65L/hrAmbient Temp.+5°C ~+35°C Power Supply AC 380V±10% 50Hz,3 phase 4 wires +Ground WiresWeight 250KGSight window sizewith LED lightSample holder 2 pcsFittingscable port(portΦ50mm)*1, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker, overpressure, over heat&over current protect, over temp. protect, overload protect for the blower, dry heat protect Control SystemBalanced Temperature & Humidity Control (BTHC)SystemRefrigeration systemAir Cooled (Water Cooled is an option)Hermetic compressor

Hermetic compressor

Single-stage refrigeration system,

CFC-Free refrigerant(HFC-507/HFC-23)

CFC-Free refrigerant(HFC-507/HFC-23)Controller7-inch LCD Touch Screen panel                                                                        Operation model: Program or fixpoint runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesNote:
1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available

5. Controller:
Digital Touch Screen
127 program, running for an extremely long time,999 hours per segment, maximum 3200 times circulation
support RS485, LAN (internet access), GPRS (mobile phone), etc. communication mode. Convenient for remote monitoring and data sampling.

Key Features:

KOMEG LCD Colour touch controller, user friendly operation
Mode: Fix or program mode
PLC microprocessor, PID Control of Temperature and Humidity
Both temperature and humidity are programmable (can have 100pattern, each pattern has 120 segment, can repeat pattern, segment or part of segment)
With digital humidity probe
With RS485/Ethernet output to computer
English window software (for PC editing, control, data storage)
All stainless steel (interior), 100mm thickness
Single door
With viewing window
With thermostats (prevent overheat)
Cable ports (50, 100 or 150mm) diameter
Protection  (MCCB circuit protection, phase protection, overheat, overcurrent etc)
Error history recording
Controller password protection
Cartridge type water tank
Auto-water refill valve and filter
Air cool or water cool
Note1 :  with -H temperature up to 180C

Note2 : Our chamber has RS485 interface and comes with software.
Customer can control the chamber by computer. Also data (temperature & humidity) can be stored in PC.
